Woodward easyYgen-3500XT 8440-2085 Generator Set Controller
The Woodward easYgen-3500XT (8440-2085, P1 Package) is a high-performance, microprocessor-based genset controller from the easYgen-3000XT series, engineered for complex multi-generator paralleling and power management. It integrates engine control, generator protection, breaker synchronization, and peer-to-peer load sharing into a compact panel-mount unit, featuring a backlit LCD and tactile keypad. Supporting up to 32 gensets and 16 LS-5 breakers via CANopen and redundant Ethernet, it delivers reliable, redundant power management for industrial, marine, and critical infrastructure.
Primary Applications
- Complex Paralleling: Synchronization and load sharing for up to 32 generators across 32 bus segments。
- Utility Intertie: Grid paralleling, islanding, and tie-breaker control for multi-utility feeders。
- Critical Power: Data centers, hospitals, and industrial facilities requiring redundant backup power。
- Marine Power Management: Paralleling of ship generators and shore connection synchronization。
- Distributed Generation: Peak shaving, load sharing, and island-mode operation for industrial microgrids。
Technical Specifications
| Specification | Details |
|---|---|
| Model | 8440-2085 (easYgen-3500XT-P1) |
| Power Supply | 8–40 Vdc (12/24 Vdc nominal); ≤15 W consumption |
| Voltage Sensing | 100–690 Vac (line-line); 50/60 Hz (40–85 Hz) |
| Current Sensing | 1 A / 5 A CT input; Class 0.5 accuracy |
| Display | 4.3-inch backlit LCD; 6-key tactile keypadWoodward |
| Communication | 2× Ethernet (Modbus TCP, redundant); CANopen (125 kBaud); RS-485 (Modbus RTU) |
| Digital I/O | 16 isolated inputs; 8 relay outputs (2 A @250 Vac) |
| Analog I/O | 4 analog inputs (0–20 mA); 2 analog outputs (0–20 mA) |
| Paralleling | Up to 32 gensets; redundant load sharing (Ethernet B) |
| Dimensions | 250 × 228 × 50 mm (9.8” × 9.0” × 2.0”) |
| Weight | ~1.75 kg (3.85 lbs) |
Environmental Specifications
| Parameter | Rating |
|---|---|
| Operating Temperature | -20°C to +70°C (-4°F to +158°F) |
| Storage Temperature | -30°C to +80°C (-22°F to +176°F) |
| Humidity | 5%–95% RH (non-condensing; ≤40°C: 85% max) |
| Altitude | Up to 4000 m (13,123 ft) without derating |
| Vibration | IEC 60068-2-6 (5–150 Hz, 0.1 mm displacement) |
| Enclosure | Powder-coated sheet metal; IP20 terminals, IP54 front panel |
Recommended easYgen-3000XT Series Products
- easYgen-3500XT-P2 (8440-2088) – Expanded I/O model with 3-phase bus monitoring and CHP optimization; ideal for cogeneration and complex distributed generation。
- easYgen-3400XT-P1 (8440-2087) – Cost-effective 16-genset controller; compact design for small-to-medium industrial and commercial backup power。
- easYgen-3400XT-P2 (8440-2089) – High-I/O variant of 3400XT; supports external I/O expansion for CHP and microgrid applications。
- easYgen-GC-3000XT – Centralized group controller; manages up to 496 gensets via CANopen/Ethernet; for large power plants and fleet management。
