Valmet DCS System D202275 ACN Communication Gateway Node Module
D202275 is the ACN communication gateway node module of Valmet D2000 DCS system, belonging to the D2000 series rack mounted communication board. D202275 serves as a data exchange gateway between the D2000 controller, upper monitoring system, and third-party subsystems, responsible for protocol conversion, data forwarding, network isolation, and achieving data interoperability between the DCS main control unit, factory LAN, and external instrument subsystems; Simultaneously manage ACN control network data traffic, ensure real-time and deterministic transmission of control messages, and have network diagnosis and fault reporting functions. Mainly used for replacing communication module spare parts and expanding system network of old D2000 DCS systems in the papermaking and pulp industries.
Parameter Specifications
| Item | Specifications |
|---|---|
| Product Type | ACN Communication Gateway Node Module |
| Part Number | D202275 |
| Applicable System | Valmet D2000 DCS System |
| Processor | 32-bit industrial processor |
| Onboard RAM | 512MB |
| Onboard Flash Memory | 256MB |
| Network Interface | 2 × 10/100Mbps Ethernet for ACN control network, 1 × service port |
| Backplane Bus | D2000 internal rack backplane bus |
| Supported Protocol | D2000 ACN proprietary protocol, Modbus TCP, OPC |
| Power Supply | 24VDC (10~30VDC wide range) |
| Max Power Consumption | 9W |
| Working Current | Max 375mA |
| Isolation Voltage | 1500VAC between field network and backplane |
| Diagnostic Function | Network link detection, bus error, hardware self-test |
| Operating Temperature | -20℃ ~ +70℃ |
| Storage Temperature | -30℃ ~ +85℃ |
| Relative Humidity | 5%~95% RH, non-condensing |
| Mounting Mode | Rack slot mounting |
| Protection Class | IP20 |
| EMC Compliance | CE Class B |
| PCB Coating | Conformal coating for harsh industrial environment |
| Net Weight | 580g |
| Dimension | Standard D2000 module size |
| Origin | Finland |
Valmet DCS System D202275 ACN Communication Gateway Node Module
Brand Introduction：
Valmet is headquartered in Finland and its automation business was formerly under Metso. In 2013, Metso’s automation business was merged into Valmet and it is a leading supplier of process industrial equipment and automation solutions for the global pulp and paper, energy, biomass, mining, and building materials industries. Its main products include complete production lines, DCS automation systems, field instruments, valves, analytical instruments, and full lifecycle spare parts and maintenance services.
Core automation products:
Valmet DNA Distributed Control System (DCS) is the main process control system of Valmet, including the old IOP series I/O and the new generation ACN series I/O hardware (D201435L CXW controller D201134L AI8C、D201136L DI16C、D201126L DI8P、D201129L DO8P、D201436L DO16C Etc.)
- Hardware: ACN rack, redundant controller module, analog input/output, digital input/output I/O card, bus communication module; Support module hot plugging, channel level fault diagnosis, wide temperature industrial working conditions, support 1:1 controller redundancy, ensuring uninterrupted continuous production.
- Software: Process control software, human-machine interface HMI, historical trends, alarm management, advanced process control APC, equipment status monitoring, asset operation and maintenance management software.
- New generation platform: DNAe , web architecture DCS, strengthened network security, suitable for key process devices such as power plants and ships.
Product features
- As a dedicated communication gateway for the D2000 system ACN network, it enables data exchange and protocol conversion between the DCS controller, upper computer, and third-party automation subsystems.
- Redundant ACN control network with dual Ethernet ports, supporting automatic switching in case of network link failures, ensuring uninterrupted transmission of process control data.
- Independently maintain service ports for engineers to configure, diagnose, and download programs online without interfering with the production control network.
- The backplane bus is electrically isolated from the network side, effectively isolating external network surges and electromagnetic interference, and protecting DCS main control and I/O cards.
- Complete hardware self diagnostic function, real-time monitoring of network links, communication messages, board hardware status, and uploading fault information to DCS system alarm.
- The panel LED indicator light intuitively displays module operation, bus communication, network port links, and fault alarm status, facilitating quick on-site troubleshooting.
- The circuit board is equipped with a three proof coating, which is resistant to moisture, fiber dust, and vibration, and is suitable for harsh working conditions in paper workshops.
- Standard D2000 rack slot installation, supports hot swapping, reduces system downtime and maintenance time for fault replacement, compatible with D2000 series backboards.
