ProSoft 6104-WA-PDPM wireless PROFIBUS DP main door control device
The ProSoft 6104-WA-PDPM is a high-performance Wireless PROFIBUS DP Master Gateway from ProSoft Technology’s ProLinx 6000 Series. It enables wireless communication between PROFIBUS DP networks and other industrial devices, eliminating the need for expensive cabling in remote or hard-to-reach locations. Designed for industrial automation, it supports reliable data transmission, protocol conversion, and seamless integration into existing control systems.
Key Applications
- Wireless PROFIBUS Networking: Connect PROFIBUS DP slaves (e.g., sensors, drives, PLCs) wirelessly to a master controller.
- Remote Monitoring & Control: Enable real-time data exchange between distributed industrial equipment and central SCADA/PLC systems.
- Legacy System Integration: Bridge traditional wired PROFIBUS networks with modern wireless infrastructure.
- Industrial IoT (IIoT) Connectivity: Facilitate data sharing between PROFIBUS devices and higher-level management systems.
- Harsh Environment Deployment: Ideal for locations where physical cabling is impractical (e.g., rotating machinery, mobile equipment).
Specifications
| Parameter | 6104-WA-PDPM |
|---|---|
| Device Type | Wireless PROFIBUS DP Master Gateway |
| Wireless Standard | IEEE 802.11 b/g (2.4 GHz ISM Band) |
| Data Rate | Up to 54 Mbps (wireless) |
| PROFIBUS Interface | DP Master, up to 12 Mbps |
| Wireless Range | Up to 300 m (line-of-sight) |
| Power Supply | 18 to 36 VDC (24 VDC nominal) |
| Power Consumption | 5 W (max) |
| Dimensions (W × H × D) | 120 mm × 80 mm × 25 mm (4.7 in × 3.1 in × 1.0 in) |
| Weight | 0.3 kg (0.66 lb) |
| Configuration | SyCon Software / ProSoft Configuration Builder |
| Protocols Supported | PROFIBUS DP, ProSoft Wireless Protocol (PWP) |
Typical Industries
- Manufacturing: Automotive, food & beverage, pharmaceuticals (wireless control of production lines).
- Oil & Gas: Offshore platforms, refineries (remote monitoring of pumps, valves, and sensors).
- Water & Wastewater Treatment: Wireless control of pumps, flow meters, and level sensors.
- Energy & Power: Power plants, renewable energy farms (connecting distributed generation assets).
- Material Handling: Ports, warehouses (wireless control of cranes, conveyors, and AGVs).
Operating Environment
| Parameter | Specification |
|---|---|
| Operating Temperature | -40 °C to +85 °C (-40 °F to 185 °F) |
| Storage Temperature | -40 °C to +85 °C (-40 °F to 185 °F) |
| Relative Humidity | 5 % to 95 % (non-condensing) |
| Altitude | Up to 3,000 m (9,843 ft) |
| Enclosure Rating | IP30 (dust-protected, no water ingress) |
| Vibration Resistance | 5 g (10 Hz to 150 Hz) |
| Shock Resistance | 30 g (11 ms duration) |
Related Series Products
-
ProSoft 6105-WA-PDPS
- Wireless PROFIBUS DP Slave Gateway (complementary to 6104-WA-PDPM).
- Enables wireless connection of PROFIBUS DP slaves to a master network.
-
ProSoft 6101-WA-ETH
- Wireless Ethernet Gateway (IEEE 802.11 b/g).
- Connects Ethernet-based devices (PLCs, HMIs) wirelessly to TCP/IP networks.
-
ProSoft 6102-WA-MCM
- Wireless Modbus RTU/TCP Master/Slave Gateway.
- Bridges Modbus serial and Ethernet networks via wireless communication.
