Triconex 9563-810 digital input external terminal board
9563-810 is a digital input external terminal board for the Triconex Tricon Safety Instrumented SIS system. Used to match DI digital input cards as signal transfer interface units between on-site equipment and system cards.
Function: To receive 24VDC discrete input signals from on-site switches, limit switches, relay contacts, etc; Complete signal filtering, fuse protection, and transfer on-site signals to the internal I/O cards of the Tricon system; Realize electrical transition between on-site lines and safety systems, provide overcurrent protection, simplify on-site wiring, facilitate maintenance and troubleshooting, and ensure stable and reliable SIS system acquisition interlocking, shutdown, and status feedback signals.
Triconex 9563-810 digital input external terminal board
| Parameter | Value |
|---|---|
| Model | 9563‑810 |
| Product family | Tricon SIS Termination Panel |
| Signal type | Digital Input |
| Input nominal voltage | 24 V DC |
| Number of channels | 32‑channel |
| Per‑channel fuse protection | Individual fuse per channel |
| Mounting | DIN‑rail mounting |
| Power consumption | ＜5 W |
| Operating temperature range | ‑40 ℃ ~ +70 ℃ |
| Storage temperature range | ‑40 ℃ ~ +85 ℃ |
| Relative humidity | 5%‑95% non‑condensing |
| Protection class | IP20 |
| Weight | 0.45 kg |
| Origin | USA |
| Safety standard | SIL3 applicable system |
Product features
- 32 channel digital input terminal interface, each channel is equipped with an independent fuse, and a single channel fault will not cause the entire board to fail, achieving channel level overcurrent protection.
- DIN rail cabinet installation, modular structure, plug-in terminal blocks, easy wiring, maintenance and replacement.
- Specially designed for Triconex TMR triple redundant security system, compatible with corresponding series of DI cards, signal matching does not require additional conversion.
- Equipped with signal filtering processing to suppress on-site electromagnetic interference and improve the reliability of switch signal acquisition.
- Onboard status indicator light provides a visual view of channel continuity and fuse faults, facilitating on-site fault location.
- Isolation transition design, sharing the risk of external line faults, protecting internal I/O cards of the system from damage caused by on-site surges and short circuits
