Ovation 5X00605G01 32 channel event/status input card
The 5X00605G01 is a high-performance 32-channel analog input module designed by Emerson (Ovation/Westinghouse) for the Ovation Distributed Control System (DCS). It accurately converts field analog signals (e.g., temperature, pressure, flow) into digital data for real-time process monitoring and closed-loop control, ensuring high reliability and precision in critical industrial automation environments.
core parameters
Number of channels: 32 isolated DI (event input)
Signal type: dry contact (passive)/wet contact (24VDC active)
Isolation: Channel to channel isolation, channel to system isolation, withstand voltage ≥ 1500VAC
Resolution: Event resolution 1ms (high-speed event capture)
Input voltage: 24VDC (backplane power supply, no external power supply required)
Power consumption: about 4W
Temperature: 0 ° C~+60 ° C (industrial grade)
Size/Weight: Single slot, approximately 244 × 137 × 98mm/0.4-0.6kg
Diagnosis: Channel open/short circuit detection, LED status indication, backplane communication diagnosis
Key Features
High density: 32 channels per card, saving cabinet slots.
Event capture: 1ms timestamp, accurately recording the timing of switch actions (suitable for SOE event sequence recording).
Wide voltage compatibility: Supports wet contacts of 12-30VDC, suitable for different on-site power supplies.
Strong isolation: Strong anti-interference, suitable for high noise environments such as frequency converters and large motors.
Backplane communication: Ovation dedicated I/O bus for real-time and deterministic data transmission.
Typical Applications
Thermal power/nuclear power/chemical Ovation system switch quantity acquisition
SOE Event Sequence Record (Accident Traceability)
Valve, pump, fan, circuit breaker status monitoring
Third party device relay output signal acquisition
Status and substitution
Discontinued status: Obsolete, G01 is an early version, and the market mainly consists of refurbished/used/inventory spare parts.
Alternative model: 1C31219G01 (32 channel DI card), compatible with functions and pins, can be directly replaced.
Difference from analog cards (important)
5X00605G01:32 channel DI (switch value), contact/event input, non AI card.
Common AI cards: such as 1C31224G01 (8-channel mA AI), 5X00070G04 (8-channel TC AI).
