ICS Triplex T8151B Trusted Communications Interface Module
The ICS Triplex T8151B is a Trusted Communications Interface Module for the Trusted™ TMR (Triple Modular Redundancy) safety system (now part of Rockwell Automation). It offloads communication tasks from the main TMR processor, delivering high‑speed, fault‑tolerant data exchange between Trusted controllers, DCS, SCADA, and field devices. Designed for SIL 3 safety integrity, it ensures secure, redundant connectivity in critical process environments.
Key Applications
- Safety Instrumented Systems (SIS): Links Trusted TMR controllers to ESD, fire & gas, and SIL 3 systems.
- DCS/SCADA Integration: Connects safety systems to plant‑wide networks (Modbus TCP, Ethernet/IP).
- High‑Speed Data Acquisition: Transmits real‑time process data and alarm/events (SOE).
- Redundant Communication: Supports dual Ethernet and multi‑serial ports for fault‑tolerant links.
- Remote I/O & Third‑Party Devices: Interfaces with Genius I/O, PLCs, and HMI systems.
Operating Environment
| Parameter | Specification |
|---|---|
| Operating Temperature | 0 °C to +60 °C (32 °F to 140 °F) |
| Storage Temperature | −25 °C to +70 °C (−13 °F to 158 °F) |
| Relative Humidity | 5%–95% RH (non‑condensing) |
| Altitude | ≤ 5,000 m |
| Vibration/Shock | 1 g (10 Hz–150 Hz); industrial shock rated |
| Protection | Conformal coated; dust/resistant enclosure |
| Certifications | IEC 61508 SIL 3, CE, UL, CSA |
Typical Industries
- Oil & Gas: ESD, pipeline monitoring, and offshore platform safety.
- Power Generation: Thermal, hydro, and combined‑cycle plant SIS/ESD.
- Chemical & Petrochemical: SIL 3 process safety and batch control.
- Metals & Mining: Furnace safety, material handling, and critical interlocks.
- Water/Wastewater: High‑reliability pump and treatment plant control.
ICS Triplex T8151B Specifications
| Parameter | T8151B |
|---|---|
| Module Type | Trusted Communications Interface (CI) |
| Backplane Power | 20–32 VDC; 10 W power dissipation |
| Communication Ports | • Dual 10/100 Mbps Ethernet (Modbus TCP, Ethernet/IP)
• 4 × RS‑232/422/485 serial ports • 1 × RS‑232 diagnostic port |
| Protocols | Modbus TCP/RTU, Ethernet/IP, DF1, custom serial |
| SOE Buffer | 4,000 event stamps (sequence of events) |
| Redundancy | TMR‑compatible; supports redundant networks |
| Diagnostics | Front‑panel LEDs; diagnostic serial port; self‑test |
| Dimensions (W × H × D) | 266 mm × 31 mm × 303 mm |
| Weight | Approx. 1.13 kg (2.5 lb) |
| Mounting | T8100/T8300 series I/O chassis slot |
| Max per System | Up to 4 modules in a Trusted system |
Related Series Products
-
T8310 Trusted TMR Processor
- Core TMR controller for Trusted systems; executes safety logic and manages I/O/communications.
- Works with T8151B for network connectivity.
-
T8461C Trusted Digital Input Module
- 24 VDC TMR digital input module; monitors safety sensors and discrete devices.
- Interfaces with T8151B for data exchange.
-
T812X Trusted Processor Interface Adapter
- Enables Modbus Master functionality for T8151B; expands communication roles.
