Honeywell FC-TSRO-0824 Digital Output Field Termination Assembly
The FC-TSRO-0824 is a Digital Output Field Termination Assembly (FTA) manufactured by Honeywell, designed for use in the company’s Safety Manager and Experion® PKS process automation and safety systems. It serves as a critical interface between the control system’s interconnection cables and field-mounted devices, providing 8 channels of isolated, relay-based, potential-free digital output for safety and control applications.
This module is purpose-built for SIL3 safety applications (per IEC 61508), ensuring high-integrity, fail-safe operation in demanding environments. It features robust relay outputs with electrical isolation, screw-terminal field wiring, and a rugged industrial design to support reliable switching of field devices.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | FC-TSRO-0824 |
| Product Type | Digital Output Field Termination Assembly (Relay Output) |
| Number of Channels | 8 independent relay output channels |
| Contact Configuration | Normally Open (NO) / Normally Closed (NC) (configurable) |
| Isolation | Channel-to-channel galvanic isolation |
| Relay Rating | 5A @ 24VDC; 3A @ 24VDC standard |
| Max Output Voltage | Up to 250 VAC / 30 VDC |
| Operating Voltage | 12–24 VDC (system) |
| Response Time | < 1 ms |
| System Compatibility | Honeywell Safety Manager, Experion PKS |
| Safety Rating | SIL 3 capable (IEC 61508) |
| Termination | Screw terminals for field wiring |
| Mounting | Standard 19-inch rack / DIN rail compatible |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5–95% RH, non-condensing |
| Certifications | CE, UL, CSA, TÜV |
| Weight | Approx. 1.0–2.0 kg |
| Key Features | Fail-safe design, optical isolation, hot-swappable capability, LED status indicators |
Primary Applications
- Oil & Gas: Offshore platforms, refineries, and pipelines for Emergency Shutdown (ESD) systems, solenoid valve control, and alarm annunciation.
- Petrochemical & Chemical: Safety interlocks, burner management, and critical process shutoff valves.
- Power Generation: Turbine control, boiler safety systems, and auxiliary equipment actuation.
- Manufacturing & Industrial Automation: Motor control, conveyor interlocks, and discrete device switching.
- Pharmaceuticals: Regulatory-compliant process control and safety systems.
