The GE IS420PVIBH1B is a high-performance I/O pack designed for critical industrial automation applications in power generation and process control systems. As part of GE’s Mark VIe series, this module serves as a vital interface between field devices and control processors, providing reliable signal conditioning and data acquisition capabilities. The IS420PVIBH1B combines rugged industrial design with advanced signal processing, making it suitable for harsh operating environments.
Engineered for reliability, the GE IS420PVIBH1B features isolated digital output channels and supports various communication protocols. Its compact design allows flexible installation in control cabinets while maintaining the high durability standards expected from GE’s industrial components.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | IS420PVIBH1B |
| Manufacturer | General Electric |
| Product Type | Digital Output I/O Pack |
| Output Type | Isolated digital output |
| Number of Channels | 16 |
| Output Voltage | 24V DC ±10% |
| Current per Channel | 0.5A (max) |
| Isolation Voltage | 1500V AC |
| Communication Protocols | PROFIBUS DP, MODBUS |
| Power Supply | 24V DC ±10% |
| Power Consumption | 15W (max) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | 120mm × 80mm × 35mm |
| Weight | 0.8kg |
| Protection Rating | IP40 |
Main Features and Advantages:
The GE IS420PVIBH1B delivers exceptional performance with its isolated digital output design, ensuring reliable operation in electrically noisy environments. Its modular architecture allows for easy system expansion and maintenance, reducing downtime and operational costs.
Safety features: The IS420PVIBH1B includes comprehensive diagnostics and short-circuit protection for each output channel. The module also features advanced thermal management and vibration-resistant components for reliable operation in demanding industrial applications.
Application Areas:
- Power Generation: Turbine control systems
- Oil & Gas: Pipeline monitoring and SCADA systems
- Chemical Processing: Safety shutdown systems
- Water Treatment: Pump control applications
- Manufacturing: Production line automation
Related Products:
- IS220PDIAH1B: Analog input version
- IS220PDOAH2B: Enhanced digital output model
- IS220PDIAH2B: High-density analog input version
- IC693ALG392: Complementary analog module
- DS200DCFBG1B: Communication interface board
Installation and Maintenance:
Installation preparation: Verify proper ESD precautions and environmental conditions before installing the GE IS420PVIBH1B. Ensure adequate clearance for ventilation and proper cable management for optimal performance.
Maintenance recommendations: Perform regular firmware updates and periodic visual inspections. The IS420PVIBH1B requires minimal maintenance but benefits from annual preventive maintenance checks to ensure long-term reliability.
Product Assurance:
GE provides a standard 12-month warranty for the IS420PVIBH1B. Each unit undergoes extensive testing to ensure reliable operation in industrial automation applications.
