B&R 4PP220.0571-K06 HMI Human Machine Operation Panel
4PP220.0571-K06 is an integrated industrial HMI human-machine operation panel of the B&R Power Panel220 series. It integrates the display touch unit, PLC controller core, and communication interface into the same panel device, and is installed through cabinet panel openings.
main function
- As a local operating terminal for the device, it enables device parameter settings, display of operating status screens, viewing of fault alarms, and manual operation control.
- Equipped with PLC computing capability, it can independently complete logic control of small and medium-sized equipment, and can also be used as an HMI slave station to interface with external X20 system controllers.
- Realize data exchange with third-party devices such as PLC, frequency converter, and instrument through Ethernet and serial port, and collect on-site process data.
- Implement program, recipe, and historical alarm data storage on CF cards; Built in backup battery ensures that SRAM and clock data are not lost during power outages.
- The aPCI expansion slot can be equipped with expansion cards to achieve I/O or communication interface expansion, adapting to more devices
B&R 4PP220.0571-K06 HMI Human Machine Operation Panel
| Item | Specification |
|---|---|
| Model | 4PP220.0571‑K06 |
| Series | Power Panel 220 |
| Display | 5.7 inch QVGA color LCD |
| Resolution | 320 × 240 pixels |
| Touch Screen | Resistive touch |
| SDRAM | 64 MB |
| SRAM | 256 kB |
| Storage Slot | CompactFlash Type‑I slot |
| Expansion Slot | 1 × aPCI slot |
| Power Supply | 24 V DC (18‑30 V DC) |
| Power Consumption | Typ.12 W |
| Communication | 10/100Mbps Ethernet, RS232, 2×USB1.1 |
| Front Protection | IP65 |
| Rear Protection | IP20 |
| Operating Temperature | -25 ℃ ~ +60 ℃ |
| Max Operation Altitude | 3000 m |
| Dimensions(W×H×D) | 212 mm × 156 mm × 76 mm |
| Weight | Approx.1.7 kg |
| Programming Software | Automation Studio |
| Mounting | Panel cut‑out mounting |
| Accessory | Power terminal block 0TB103.9 / 0TB103.91(ordered separately) |
