The Bently 330101-00-40-05-02-00 is a high-performance 8mm proximity sensor system from the renowned 3300 XL series, designed for critical machinery monitoring in industrial applications. As part of Bently Nevada’s flagship condition monitoring portfolio, the 330101-00-40-05-02-00 provides precise measurement of shaft position, vibration, and speed in rotating equipment.
This robust sensor system combines exceptional measurement accuracy with reliable operation in harsh industrial environments. The Bently 330101-00-40-05-02-00 features advanced signal processing capabilities and is compatible with most major monitoring systems, making it a versatile solution for predictive maintenance programs.
Technical Specifications
Parameter NameParameter Value
Model: 330101-00-40-05-02-00
Manufacturer:Bently Nevada
Product Type:3300 XL 8mm Proximity Sensor System
Measurement Range:0.25 to 2.3 mm (10 to 90 mils)
Frequency Response:0 to 15 kHz
Operating Temperature:-40°C to +120°C (-40°F to +250°F)
Output Signal:-4 to -20 VDC
Power Supply:18-30 VDC
Cable Length:5m standard (custom lengths available)Housing MaterialStainless Steel 316Environmental RatingIP67CertificationsATEX, IECEx, CSA
Main Features and Advantages:
The Bently 330101-00-40-05-02-00 delivers superior measurement accuracy with ±1% linearity across its full operating range, ensuring reliable monitoring of critical machinery parameters. Its rugged stainless steel construction provides exceptional durability in challenging industrial environments.
Advanced diagnostics: Built-in self-test capabilities and continuous signal validation ensure measurement integrity. The 330101-00-40-05-02-00 features temperature-compensated electronics for stable performance across wide temperature ranges.
3300 XL 8 mm Proximity Transducer System PDF
3300 XL 8 mm Proximity Transducer System
Application Areas:
- Power Generation: Steam and gas turbine monitoring
- Oil & Gas: Compressor and pump monitoring
- Petrochemical: Critical rotating equipment protection
- Water Treatment: Large pump vibration monitoring
- Mining: Heavy machinery condition monitoring
Related Products:
- 3BHE023784R0001 5SHY3545L0014 IGBT semiconductor switching device
- GE Electric丨IS220UCSAH1A PAMC Acoustic Monitor (processor)
- BENTLY 3500/22M 288055-01 digital input module
- TRICONEX 3009 MP UMP -Unified Main Processor
- FCP280 RH924YA FOXBORO Field Control processor
- ProTech 203 9907-147 Industrial Grade overspeed protection Unit
- Honeywell CC-PAIH51 high-performance analog input modul
Installation and Maintenance:
Installation preparation: Verify proper mounting location and ensure clean, debris-free target surface before installing the Bently 330101-00-40-05-02-00. Check power supply specifications and cable routing requirements.
Maintenance recommendations: Perform annual calibration checks and visual inspections. The 330101-00-40-05-02-00 requires minimal maintenance due to its robust design and sealed construction.
Product Assurance:
Bently Nevada offers a 12-month warranty for 330101-00-20-10-02-00. Each unit undergoes rigorous factory testing to ensure reliable performance in critical applications.
