Bently 330101-00-20-10-02-05 8mm proximity sensor

The Bently 330101-00-20-10-02-05 is a high-performance 8mm proximity sensor system from the renowned 3300 XL series, designed for critical machinery monitoring in industrial applications. As part of Bently Nevada’s flagship condition monitoring portfolio, the 330101-00-20-10-02-05 provides precise measurement of shaft position, vibration, and speed in rotating equipment.

This robust sensor system combines exceptional measurement accuracy with reliable operation in harsh industrial environments. The Bently 330101-00-20-10-02-05 features advanced signal processing capabilities and is compatible with most major monitoring systems, making it a versatile solution for predictive maintenance programs.

Technical Specifications

Parameter NameParameter Value

Model: 330101-00-20-10-02-05
Manufacturer：Bently Nevada
Product Type：3300 XL 8mm Proximity Sensor System
Measurement Range：0.25 to 2.3 mm (10 to 90 mils)
Frequency Response：0 to 15 kHz
Operating Temperature：-40°C to +120°C (-40°F to +250°F)
Output Signal：-4 to -20 VDC
Power Supply：18-30 VDC
Cable Length：5m standard (custom lengths available)Housing MaterialStainless Steel 316Environmental RatingIP67CertificationsATEX, IECEx, CSA

Main Features and Advantages:

The Bently 330101-00-20-10-02-05 delivers superior measurement accuracy with ±1% linearity across its full operating range, ensuring reliable monitoring of critical machinery parameters. Its rugged stainless steel construction provides exceptional durability in challenging industrial environments.

Advanced diagnostics: Built-in self-test capabilities and continuous signal validation ensure measurement integrity. The 330101-00-20-10-02-05 features temperature-compensated electronics for stable performance across wide temperature ranges.

3300 XL 8 mm Proximity Transducer System PDF

3300 XL 8 mm Proximity Transducer System

Application Areas:

Power Generation: Steam and gas turbine monitoring
Oil & Gas: Compressor and pump monitoring
Petrochemical: Critical rotating equipment protection
Water Treatment: Large pump vibration monitoring
Mining: Heavy machinery condition monitoring

Installation and Maintenance:

Installation preparation: Verify proper mounting location and ensure clean, debris-free target surface before installing the Bently 330101-00-20-10-02-05. Check power supply specifications and cable routing requirements.

Maintenance recommendations: Perform annual calibration checks and visual inspections. The 330101-00-20-10-02-05 requires minimal maintenance due to its robust design and sealed construction.

Product Assurance:

Bently Nevada offers a 12-month warranty for 330101-00-20-10-02-00. Each unit undergoes rigorous factory testing to ensure reliable performance in critical applications.
