The ZYGO PC200 8070-0102-01X is a high-precision laser interferometer designed for ultra-precise displacement measurement and surface profiling in industrial metrology applications. As part of ZYGO’s PC200 series, this advanced optical instrument delivers nanometer-level measurement accuracy with exceptional stability and repeatability. The PC200 8070-0102-01X features a compact design with integrated environmental compensation, making it ideal for both laboratory and production floor applications.
Engineered for demanding measurement tasks, the ZYGO PC200 8070-0102-01X combines HeNe laser technology with advanced phase detection algorithms to achieve sub-nanometer resolution. Its modular architecture allows flexible integration with automated inspection systems and CNC machine tools. The interferometer serves as a critical quality control tool in precision manufacturing, providing traceable measurements that meet international standards.
Technical Specifications
Parameter NameParameter ValueModelPC200 8070-0102-01XManufacturerZYGOTypeLaser InterferometerLaser SourceStabilized HeNe, 632.8nmMeasurement RangeUp to 60mResolution0.1nmAccuracy±0.5ppmMeasurement SpeedUp to 4m/sInterfaceUSB 3.0, EthernetOperating Temperature15°C to 35°CRelative Humidity<80% non-condensingPower Requirements100-240V AC, 50/60HzDimensions350mm × 250mm × 150mmWeight8.5kgCertificationsISO 9001, CE
Main Features and Advantages:
The ZYGO PC200 8070-0102-01X delivers unmatched measurement precision through its thermally stabilized laser source and advanced environmental compensation. Its rugged design incorporates vibration isolation and thermal management features that ensure reliable performance in industrial environments. The interferometer’s intuitive software interface simplifies setup and data analysis while providing comprehensive measurement reports.
Unique capabilities: Real-time compensation for air temperature, pressure, and humidity variations. The PC200 8070-0102-01X supports multiple measurement modes including linear displacement, angular measurement, and straightness analysis. Its modular design allows easy reconfiguration for different measurement applications without requiring realignment.
Application Areas:
- Semiconductor: Wafer stage calibration
- Aerospace: Aircraft component inspection
- Automotive: Engine block measurement
- Machine Tools: CNC positioning verification
- Optics: Lens surface profiling
Related Products:
- ZYGO ZMI2002 8020-0211 6U VME Dual Axis Measurement Board丨ZMI 2000 System
- ALSTOM VPS 12004-102-03 Embedded I/O module
- PC200 8070-0104-01X: Multi-axis configuration
- PC200 8070-0105-01X: Environmental sensor kit
- PC200 8070-0106-01X: Vibration isolation base
Installation and Maintenance:
Installation preparation: Ensure stable mounting surface and proper environmental controls when installing the ZYGO PC200 8070-0102-01X. Verify electrical supply meets specifications and allow sufficient warm-up time for laser stabilization.
Maintenance recommendations: Perform annual calibration verification using certified reference standards. Keep optical components clean using approved cleaning procedures and regularly inspect cable connections. The PC200 8070-0102-01X requires minimal routine maintenance when operated within specified environmental conditions.
Product Assurance:
ZYGO provides 12-month warranty coverage for the PC200 8070-0102-01X, including global technical support and calibration services. Each instrument undergoes rigorous performance verification before shipment. Lifetime product support ensures long-term availability of software updates and spare parts.
