The ZYGO 8010-0105-01 is a high-performance power supply module specifically designed for ZMI laser systems and 501A electronic units in precision measurement applications. As part of ZYGO’s 8000 series power solutions, this robust module delivers stable, clean power with exceptional voltage regulation for sensitive metrology equipment. The 8010-0105-01 features advanced thermal management and EMI filtering to ensure reliable operation in demanding industrial environments.
Engineered for mission-critical applications, the ZYGO 8010-0105-01 provides multiple output voltages with precise current limiting and overvoltage protection. Its compact design allows seamless integration into existing ZYGO measurement systems while maintaining compatibility with various laser and electronic configurations. The module serves as a critical power distribution hub in optical measurement systems, ensuring consistent performance of connected devices.
Technical Specifications
Parameter NameParameter ValueModel8010-0105-01ManufacturerZYGOTypePower Supply ModuleInput Voltage100-240V AC, 50/60HzOutput Voltages+5V, ±15V, +24V DCOutput Current5A (max per channel)Voltage Regulation±1%Ripple Noise<50mV p-pEfficiency>85%Operating Temperature0°C to 50°CStorage Temperature-20°C to 70°CDimensions200mm × 150mm × 50mmWeight1.8kgCertificationsCE, UL, RoHS
Main Features and Advantages:
The ZYGO 8010-0105-01 delivers exceptional power stability with its multi-stage filtering and precision voltage regulation. Each output channel features independent protection circuits including overcurrent, overvoltage, and thermal shutdown. The module’s forced air cooling design ensures reliable operation even under continuous full load conditions.
Advanced diagnostics: Built-in status indicators for each power rail and comprehensive fault reporting. The 8010-0105-01 provides galvanic isolation between input and output circuits to prevent ground loops. Its rugged metal enclosure provides excellent EMI shielding and mechanical protection for sensitive internal components.
Application Areas:
- Semiconductor: Wafer inspection systems
- Aerospace: Component measurement stations
- Automotive: Precision alignment equipment
- Research Labs: Optical interferometry systems
- Manufacturing: High-accuracy metrology tools
Related Products:
- ZMI 2000 System ZMI-2002 8020-0211 Measurement Boards
- Xycom 83060CA high-performance processor board module
- 8010-0107-01: DIN rail mount version
- 8010-0108-01: Redundant power module
- 8010-0109-01: Extended temperature range model
Installation and Maintenance:
Installation preparation: Verify proper ventilation and clearance around the ZYGO 8010-0105-01 module before installation. Ensure input voltage matches local power supply specifications and use appropriate gauge wiring for all connections.
Maintenance recommendations: Perform annual inspection of all electrical connections and cooling system. Monitor output voltages periodically using calibrated measurement equipment. The 8010-0105-01 requires minimal routine maintenance when operated within specified environmental conditions.
Product Assurance:
ZYGO provides 12-month warranty coverage for the 8010-0105-01, including global technical support and repair services. Each module undergoes comprehensive burn-in testing and performance verification before shipment. Lifetime product support ensures long-term availability of spare parts and technical documentation.
