The Xycom 83594BD is a high-performance industrial control card designed for mission-critical automation applications in harsh environments. As part of Xycom’s 83000 series industrial control solutions, the 83594BD delivers exceptional processing capabilities and reliable I/O interfacing for both PLC and DCS control systems.
Featuring ruggedized construction with conformal coating protection, the Xycom 83594BD is engineered to withstand extreme industrial conditions including wide temperature variations (-40°C to +85°C) and mechanical vibrations. Its modular design enables seamless integration with various industrial control systems, providing system integrators with flexible automation solutions for process and discrete manufacturing applications.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | 83594BD |
| Manufacturer | Xycom |
| Type | Control Card |
| Processor | Dual-core 1.8GHz Industrial CPU |
| Memory | 2GB DDR3 |
| Storage | 16MB Flash |
| Operating Temperature | -40°C to +85°C |
| Power Supply | 24V DC ±10% |
| Digital I/O | 32 channels |
| Analog Inputs | 8 channels (16-bit) |
| Communication Protocols | Modbus RTU/TCP, Ethernet/IP |
| Dimensions | 120×80×25mm |
Key Features and Advantages:
Industrial reliability: The Xycom 83594BD features extended temperature operation and vibration-resistant design, ensuring stable performance in challenging industrial environments. The conformal coating provides additional protection against dust and moisture ingress.
Flexible control capabilities: With 32 digital I/O channels and 8 high-precision analog inputs, the 83594BD offers versatile control options for various automation tasks. Support for multiple industrial protocols including Modbus and Ethernet/IP enables seamless integration with different control systems.
Application Areas:
- Manufacturing Automation: PLC-based control in automotive and electronics production lines
- Process Industries: DCS integration for chemical and pharmaceutical plants
- Energy Management: Control systems for power generation and distribution
- Water Treatment: Monitoring and control applications for municipal facilities
Related Products:
- Xycom 81625DA industrial PC board
- Xycom 2060LCD Industrial Liquid Crystal Display Upgrade Kit
- 83600BD: High-performance model with quad-core processor
- 83594-IO: Complementary I/O expansion module
- 83594-NET: Industrial network interface kit
Installation and Maintenance:
Installation preparation: Verify control system compatibility and ensure proper grounding before installing the 83594BD control card. Allow adequate space (minimum 30mm clearance) for heat dissipation in control cabinets.
Maintenance recommendations: Perform annual inspections of connectors and cooling surfaces. Monitor system logs for early fault detection. Regular firmware updates are recommended to maintain optimal performance and security.
Product Assurance:
Xycom provides 12-month warranty coverage for the 83594BD, including technical support and repair services. Each unit undergoes comprehensive environmental testing including thermal cycling and vibration tests to ensure reliability in industrial applications.
