The Woodward 8200-1302 is a marine-grade steam turbine control module from the 505D Digital Control System series, specifically engineered for propulsion and power generation control in harsh maritime environments. As part of Woodward’s Naval Solutions portfolio, the 8200-1302 delivers ±0.05% speed regulation accuracy for cruise ship auxiliary turbines operating under IEC 60092-501 shock/vibration standards. Its triple-redundant CANbus architecture maintains thrust bearing protection during 45° hull rolls in North Sea offshore service vessels.
Designed for MIL-STD-461G EMI compliance, the Woodward 8200-1302 features salt spray-resistant aluminum housing (ISO 12944-C5M class) capable of withstanding 98% humidity in tropical marine environments. The module’s 200ms fault detection time prevents overspeed conditions in LNG carrier re-liquefaction plant turbines. With native NMEA 2000 integration, it enables real-time power management synchronization between main engines and shaft generators in Ro-Pax ferries.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 8200-1302 |
| Manufacturer | Woodward |
| Product Type | 505D Marine Turbine Controller |
| Input Voltage | 24VDC ±15% (18-32VDC) |
| Processor | Dual-core ARM Cortex-A9 @ 800MHz |
| Control Loops | 8 independent PID channels |
| Response Time | <10ms for overspeed protection |
| Communication | 2x CANbus, 1x NMEA 2000, RS-485 |
| Operating Temp | -25°C to +70°C |
| Vibration | 7g RMS (IEC 60945) |
| Housing Rating | IP66/IP67 (selectable) |
| Certifications | DNV GL, ABS, Lloyd’s Register |
| Dimensions | 320x210x85mm (WxHxD) |
Key Features and Advantages:
Military marine durability: The Woodward 8200-1302 uses gold-plated contacts resistant to sulfurous atmospheres in heavy fuel oil (HFO) power plants. Proprietary anti-corrosion coating withstands 5,000hr salt fog testing per ASTM B117.
Advanced turbine protection: Implements Woodward’s patented Swing Equation algorithm that predicts rotor stress 8 seconds ahead in naval destroyer turbines. Automatic load shedding maintains 60Hz grid stability during blackout recovery on hospital ships.
Human-machine interface: Integrated 7″ sunlight-readable touchscreen displays bearing temperature trends and steam chest pressures. Role-based access control complies with IMO MSC.1/Circ.1512 cyber resilience requirements.
Application Areas:
The Woodward 8200-1302 excels in:
- LNG Carriers: Boil-off gas compressor anti-surge control
- Naval Vessels: Combined gas turbine/diesel (CODOG) mode switching
- Cruise Ships: Hotel load power sharing optimization
- Offshore Support: Dynamic positioning thruster coordination
In Arctic icebreakers, its cold-start capability maintains control valve calibration at -30°C. The module’s MIL-STD-1399 Section 380B compliance prevents electromagnetic interference with radar systems on coast guard cutters.
Related Products:
- ProTech-GII Woodward 5437-1119 Spare module for safety device
- WOODWARD 9908-1501 GS16 gas control valve
- Woodward’s ProAct™XPC platform integrates the 9907-1200
- High performance servo driver BUM60-1224-54-B-001-VC-A0-0093-0013-G003-000 3522-1004
- Woodward 9907-147 power trip overspeed protection system
- Woodward 8237-1604 Safety PLC controller with integrated overspeed protection
- 8200-CANF: CANbus fiber optic converter
Installation and Maintenance:
Installation preparation: Ensure proper shock mounts (per MIL-S-901D Grade A) are installed before mounting Woodward 8200-1302 in engine control rooms. Use tinned copper cables with DGUV-003 marine-grade insulation for all signal connections.
Maintenance recommendations: Perform quarterly dielectric strength tests on power terminals in high-sulfur environments. Calibrate speed sensors every 2,000 operating hours using Woodward’s 505 QuickServ toolkit. Replace anti-vibration gaskets every 5 years in accordance with OEM service bulletin MCS-2022-15.
Product Assurance:
Woodward provides 12-month warranty for 8200-1302, including 24/7 technical support through 35 global marine service centers. Each unit undergoes 500-hour marine environmental testing simulating tropical/arctic conditions. Certified repair deputs guarantee 48-hour turnaround for all DNV-classified vessels.
8200-1304：VANTAGE GC (LV-ATX & MARINE) STEAM TURBINE CONTROL
8200-1312：505XT (LV-ATX & MARINE) STEAM TURBINE CONTROL
8200-1314：VANTAGE XC (LV-ATX & MARINE) STEAM TURBINE CONTROL
8200-1342：FLEX500 (LV-ATX & MARINE), WITHOUT GUI AND MAIN APPLICATION SW
8200-1345：FLEX500 (LV-ATX & MARINE), WITHOUT GUI AND MAIN APPLICATION SW
8200-2302：505D (LV-ATX) STEAM TURBINE CONTROL
8200-2304：VANTAGE GC (LV-ATX) STEAM TURBINE CONTROL
8200-2312：505XT (LV-ATX) STEAM TURBINE CONTROL
8200-2314：VANTAGE XC (LV-ATX) STEAM TURBINE CONTROL
8200-2342：FLEX500 (LV-ATX), WITHOUT GUI AND MAIN APPLICATION SW
8200-2345：FLEX500 (LV-ATX), WITHOUT GUI AND MAIN APPLICATION SW
