The Bosch Rexroth VT-HNC100-4-3X/P-I-00/G04 represents the cutting-edge of servo drive technology, designed for high-precision motion control applications in industrial automation systems. As part of Rexroth’s IndraDrive platform, this compact yet powerful servo amplifier delivers exceptional dynamic response with 400V AC three-phase input and 4kW continuous output power. The VT-HNC100-4-3X/P-I-00/G04 integrates advanced control algorithms including adaptive vibration suppression and automatic resonance damping, making it ideal for demanding CNC machinery and robotic applications.
Featuring dual Ethernet interfaces (EtherCAT and PROFINET), the Bosch Rexroth VT-HNC100-4-3X/P-I-00/G04 enables seamless integration into Industry 4.0 environments with real-time communication capabilities ≤1ms cycle time. Its modular design allows flexible configuration with optional safety functions (STO, SS1, SLS per SIL3/PLe) and supports various feedback systems including absolute encoders with Hiperface DSL interface. The VT-HNC100-4-3X/P-I-00/G04 sets new standards in energy efficiency with regenerative braking capability and 95%+ power conversion efficiency.
Technical Specifications
Product Model | VT-HNC100-4-3X/P-I-00/G04
Manufacturer | Bosch Rexroth
Product Type | Servo Amplifier
Rated Power Output | 4kW (continuous)
Input Voltage | 3×400V AC (-15%/+10%)
Output Current | 8.5A RMS (continuous)
Communication Protocols | EtherCAT, PROFINET, SERCOS III
Control Cycle Time | ≤1ms (EtherCAT)
Feedback Interfaces | EnDat 2.2, Hiperface DSL, Resolver
Safety Functions | STO, SS1, SLS (SIL3/PLe optional)
Efficiency | >95% (typical)
Regenerative Braking | Integrated (external resistor optional)
Protection Class | IP20
Operating Temperature | 0°C to 45°C (32°F to 113°F)
Storage Temperature | -25°C to 85°C (-13°F to 185°F)
Dimensions (W×H×D) | 185×245×205mm
Weight | 5.8kg
Certifications | CE, UL, cULus
Key Features and Advantages:
The VT-HNC100-4-3X/P-I-00/G04 revolutionizes motion control with its patented “Adaptive Tuning Technology” that automatically compensates for mechanical resonance and load variations without manual parameter adjustment. Dual-processor architecture separates communication and control tasks, ensuring jitter-free performance even during network load peaks.
Precision control: Achieves positioning accuracy ≤±1 encoder count with 24-bit resolution and 50μs current loop update rate. The amplifier’s “One Cable Technology” option reduces wiring complexity by transmitting power and feedback signals through a single hybrid cable. Maintenance teams benefit from integrated condition monitoring that tracks component wear (capacitors, fans) and predicts service intervals via web interface.
Application Fields:
In CNC machining centers, the VT-HNC100-4-3X/P-I-00/G04 drives high-speed spindles (up to 30,000 RPM) with precision tool path following accuracy ≤5μm. Automotive production lines utilize its synchronous control capabilities for robotic welding arms requiring ≤0.01° angular repeatability.
Packaging machinery applications leverage the amplifier’s electronic cam profile functionality for complex motion sequences, while semiconductor equipment benefits from its ultra-low ripple current (<0.5% of rated current) for sensitive positioning tasks. The Bosch Rexroth VT-HNC100-4-3X/P-I-00/G04 is particularly effective in printing presses where its 100μs synchronization accuracy ensures register mark alignment.
Related Products:
- VT-HNC80-4-3X/P-I-00/G04 – 3kW version of same platform
- VT-HNC140-4-3X/P-I-00/G04 – 7kW higher power variant
- MSK060C-0300-NN-M1-UG0 – Matching synchronous servo motor
- HCS01.1E-W0013-A-03 – System controller for multi-axis coordination
- R911404020 – External braking resistor kit
Installation and Maintenance:
Installation preparation: The VT-HNC100-4-3X/P-I-00/G04 requires minimum 100mm clearance on all sides for ventilation and should be mounted vertically on non-flammable surfaces. Verify mains voltage stability (±10% tolerance) and implement proper RFI filtering for CE compliance.
Maintenance recommendations: Perform quarterly cleaning of cooling fins using compressed air (<2bar pressure). Monitor DC link capacitor health via web interface and replace when ESR exceeds 150% of initial value. Firmware updates should be scheduled during planned downtime using Rexroth’s IndraWorks engineering tool.
Product Assurance:
Bosch Rexroth provides a 12-month warranty for the VT-HNC100-4-3X/P-I-00/G04, covering all material and manufacturing defects.
There are no reviews yet.
