PPD113B03-10-150000 3BHE023584R1023‌ Digital Excitation controller

$15,913.00

In stock

The ‌ABB PPD113B03-10-150000 3BHE023584R1023‌ is a high-performance digital excitation controller from ABB’s AC800PEC series, engineered for precise voltage regulation in power generation systems. This advanced device combines dual redundant ARM Cortex-A9 processors with 150kA interrupting capacity, delivering ±0.25% voltage regulation accuracy for hydroelectric generator control. The ‌PPD113B03-10-150000 3BHE023584R1023‌ implements IEC 61850-compliant communication, enabling seamless integration with smart grid protection relays.

The ‌ABB PPD113B03-10-150000 3BHE023584R1023‌ is a high-performance digital excitation controller from ABB’s AC800PEC series, engineered for precise voltage regulation in power generation systems. This advanced device combines dual redundant ARM Cortex-A9 processors with 150kA interrupting capacity, delivering ±0.25% voltage regulation accuracy for hydroelectric generator control. The ‌PPD113B03-10-150000 3BHE023584R1023‌ implements IEC 61850-compliant communication, enabling seamless integration with smart grid protection relays.

As a core component of ABB’s System 800xA platform, this controller features <2ms response time for under-excitation limiters in gas turbine plants. Its 4-channel isolated analog inputs (4-20mA/±10VDC) interface with turbine speed sensors in nuclear power stations. The ‌ABB PPD113B03-10-150000 3HE023584R1023‌ supports dual LAN ports with PRP/HSR redundancy protocols, ensuring uninterrupted operation in offshore wind farm collector stations.

Technical Specifications

Parameter Name Parameter Value
Product Model PPD113B03-10-150000 3BHE023584R1023
Manufacturer ABB
Product Type Digital Excitation Controller
Input Voltage 24VDC ±20% (redundant)
Field Current 0-15000A DC (continuous)
Voltage Regulation ±0.25% of setpoint
Response Time <2ms (95% step response)
Communication Protocols IEC 61850, Modbus TCP, PROFIBUS DP
Operating Temperature -25°C to +70°C
Protection Class IP54 (front), IP20 (terminals)
Dimensions 482×177×218mm (19″ rack)
Certifications UL 508, IEC 60068-2
MTBF 300,000 hours
Weight 12.5kg

Key Features and Advantages:

Adaptive control algorithms: The ‌PPD113B03-10-150000 3BHE023584R1023‌ employs self-tuning PID with neural network compensation, maintaining grid code compliance during load rejection in pumped storage plants. Dual watchdog timers guarantee fail-safe operation in coal-fired power station exciter systems.

Cybersecurity hardened: Implements IEC 62443-3-3 SL2 security with role-based access control for substation automation. Encrypted firmware updates prevent unauthorized modifications in geothermal power plants.

Diagnostic intelligence: Built-in partial discharge monitoring (0-500pC range) detects stator insulation degradation in marine generator sets. Event recorder stores 10,000 time-stamped alarms with µs resolution for post-fault analysis.

Application Areas:

The ‌ABB PPD113B03-10-150000 3BHE023584R1023‌ is essential for:

  • Hydropower‌: Synchronous condenser reactive power control
  • Steel Mills‌: Motor-generator set excitation management
  • Mining‌: Ball mill drive system power factor correction
  • Marine‌: LNG carrier shaft generator regulation

In aluminum smelters, its harmonic compensation (THD <1.5% at 50Hz) prevents rectifier-induced voltage distortion. The controller’s 150kA DC breaking capacity protects offshore drilling rig generators during short circuits. Seismic-certified design (IEC 60980 Class 1) ensures operation in earthquake-prone regions.

Related Products:

  1. PPD113B01-25-111001 3BHE023784R2530 Control system AC800PEC
  2. AC800PEC PCD230A101 3BHE022291R0101 ABB excitation controller
  3. ‌ABB GFD233A103 3BH022294R0103 AC800PEC Rectifier control module
  4. ‌AC800PEC PCD530A102 3BHE041343R0102 UNITROL 6000 X-power controller
  5. PPD 115 A102 UNITROL 6000 X-power controller
  6. ‌3BHE039770R0102 PPD539 A102
  7. ‌PPD117A3011 3BHE030410R3011

AC800PEC_高性能控制系统

Installation and Maintenance:

Installation preparation: Verify insulation resistance (>100MΩ @ 500VDC) between field terminals before energizing ‌PPD113B03-10-150000 3BHE023584R1023‌. Use ABB FCM Calibration Suite to initialize controller parameters.

Maintenance recommendations: Perform annual dielectric test (3.5kV AC, 1 minute) on field wiring. Clean air filters quarterly using ABB SFG-1200 maintenance kit in dusty environments. Update firmware during planned downtime using ABB Asset Suite 4.0.

Product Assurance:

ABB provides 12 months comprehensive warranty for ‌PPD113B03-10-150000 3BHE023584R1023‌, including 24/7 technical support. Each unit undergoes 72-hour heat run test at 125% rated current. Our global service network guarantees 48-hour emergency response for critical power infrastructure.
