The ABB PM864AK01 3BSE018161R1 is a high-performance industrial automation controller from ABB’s renowned AC800M series. Designed as the brain of distributed control systems (DCS), this processor module delivers exceptional computing power for complex automation applications1. The PM864AK01 3BSE018161R1 serves as the central processing unit in ABB’s automation architecture, executing control algorithms and managing communication across the entire system.
Featuring advanced processing capabilities, the ABB PM864AK01 3BSE018161R1 supports multiple communication protocols including PROFIBUS and OPC, making it ideal for integration with various field devices and enterprise systems. Its robust design ensures reliable operation in demanding industrial environments, maintaining ABB’s high standards for automation components.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | PM864AK01 3BSE018161R1 |
| Manufacturer | ABB |
| Product Type | AC800M Processor Module |
| Processor Type | 32-bit RISC |
| Clock Speed | 1.2 GHz |
| Memory | 512MB RAM, 512MB Flash |
| Communication Ports | 2×Ethernet, 2×PROFIBUS DP |
| Supported Protocols | MODBUS, OPC, PROFIBUS, TCP/IP |
| Power Supply | 24V DC ±10% |
| Power Consumption | 15W |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Protection Rating | IP20 |
| Dimensions | 210mm × 120mm × 75mm |
| Weight | 1.8kg |
Main Features and Advantages:
The ABB PM864AK01 3BSE018161R1 stands out with its powerful processing capabilities, capable of handling up to 10,000 function blocks simultaneously. Its dual-core architecture ensures smooth execution of both control algorithms and communication tasks without performance degradation.
Redundancy support: The module features built-in redundancy capabilities, allowing for hot-swappable operation in critical applications1. The PM864AK01 3BSE018161R1 also includes advanced diagnostic functions that provide detailed system status information for proactive maintenance.
Application Areas:
- Power Generation: Turbine control systems6
- Oil & Gas: Pipeline monitoring and control
- Chemical Processing: Reactor automation
- Water Treatment: Distributed control systems
- Manufacturing: Process automation
Related Products:
- PM865AK01: Higher performance variant with additional memory
- PM866AK01: Compact version for space-constrained installations
- PM867AK01: Extended temperature range model
- CI854AK01: Communication interface module
- TB811AK01: Termination board for I/O expansion
Installation and Maintenance:
Installation preparation: Verify proper mounting location and cooling requirements before installing the ABB PM864AK01 3BSE018161R1. Ensure adequate clearance for ventilation and proper cable management for optimal performance.
Maintenance recommendations: Perform regular firmware updates and periodic visual inspections. The PM864AK01 3BSE018161R1 requires minimal maintenance but benefits from annual preventive maintenance checks.
Product Assurance:
ABB provides a standard 12-month warranty for the PM864AK01 3BSE018161R1. Each unit undergoes extensive testing to ensure reliable operation in industrial automation applications.
