The ABB PFRL101C-2.0kN 3BSE002964R002 represents a high-precision radial force measurement cell designed for industrial automation systems requiring accurate mechanical load monitoring. As part of ABB’s PFRL100 series of compact force sensors, this 2.0kN-rated device achieves ±0.3% FS accuracy through proprietary strain gauge technology, specifically engineered for robotic assembly press-fit applications. The PFRL101C-2.0kN 3BSE002964R002 features IP67-rated stainless steel housing capable of withstanding 500g shock loads in automotive production line environments while maintaining measurement stability from -25°C to +85°C.
Equipped with M12-5pin quick-connect interface, this force transducer integrates seamlessly with PLC-controlled quality assurance systems. The 3BSE002964R002 variant incorporates temperature-compensated digital signal processing that reduces thermal drift by 60% compared to analog models, making it ideal for semiconductor wafer handling equipment requiring micron-level positioning accuracy.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | PFRL101C-2.0kN 3BSE002964R002 |
| Manufacturer | ABB |
| Product Type | Radial Force Measurement Cell |
| Rated Capacity | 2.0kN (2000N) |
| Overload Capacity | 150% FS |
| Accuracy | ±0.3% FS (non-linearity + hysteresis) |
| Output Signal | 4-20mA / 0-10VDC |
| Supply Voltage | 10-30VDC |
| Protection Class | IP67/IP69K (optional) |
| Operating Temp | -25°C to +85°C |
| Storage Temp | -40°C to +100°C |
| Interface | M12-5pin (A-coded) |
| Response Time | <1ms |
| Cable Length | 2m standard (shielded) |
| Material | 17-4 PH stainless steel |
| Compliance | CE, RoHS, EN 837-1 |
Key Features and Advantages:
Ultra-compact design: The PFRL101C-2.0kN delivers 0.01N resolution in a 35mm diameter form factor, enabling direct integration into robotic end-effector tooling. Its symmetrical radial design eliminates directional sensitivity errors common in cantilever-type sensors.
Environmental resilience: Hermetically sealed laser-welded construction prevents lubricant ingress in food processing machinery. The sensor’s nickel-plated sensing element resists chemical corrosion in pharmaceutical tablet compression systems.
Smart diagnostics: Built-in self-monitoring function detects cable breaks and signal anomalies, triggering immediate PLC alarms in battery module assembly presses. Optional IO-Link interface enables real-time parameter configuration without disassembly.
Application Areas:
The 3BSE002964R002 excels in:
- Automotive: EV battery stack compression monitoring
- Electronics: Connector insertion force verification
- Packaging: Blister pack sealing pressure control
- Aerospace: Composite material layup force profiling
In robotic screwdriving stations, its 20kHz sampling rate captures peak torque transients during critical fastener installation. The sensor’s 0.02% repeatability ensures consistent crimping force in medical device wire harness production lines.
Related Products:
- ABB PFVO 142 3BSE023732R1 Signal conditioning module
- Acid proof type PFTL 201BER-20.0KN 3BSE023161R1 Pillow block tensiometer
- ABB PFEA113-65 3BSE050092R65 Tension control module
- Transmission system PFSA103D 3BSE002492R0001 Signal transmission unit
- PFTL 101BE-5.0KN 3BSE004215R1 Strip tension measurement applications
- AC 800 PEC GFD563A102 3BHE046836R0102 low-speed process control
- AO2040 Continuous gas analyzers-Measurement made easy
Installation and Maintenance:
Installation preparation: Perform zero-point calibration using ABB ForceMaster software before mounting the PFRL101C-2.0kN in parallel robotic pick-and-place systems. Ensure minimum 15mm clearance around sensor body for thermal expansion in foundry applications.
Maintenance recommendations: Clean measuring surfaces quarterly with isopropyl alcohol in CNC machine tool loading stations. Verify calibration accuracy every 50,000 cycles using NIST-traceable reference weights. Replace wear pads annually in high-cycle stamping press installations.
