Motorola MVME7616E-001 conversion module

The Motorola MVME7616E-001 is a high-performance 8-bit SCSI conversion module designed specifically for integration with MVME5100 series industrial computing platforms. This rugged MVME7616E-001 module serves as a critical interface bridge between legacy industrial equipment and modern control systems, maintaining compatibility with various SCSI-1 and SCSI-2 peripheral devices while delivering reliable data transfer rates up to 5MB/s. As part of Motorola’s proven MVME product line, the MVME7616E-001 features military-grade construction that withstands harsh industrial environments with vibration and temperature fluctuations. The module’s intelligent design includes automatic termination detection and configurable ID addressing, making the MVME7616E-001 an ideal solution for industrial automation system upgrades where legacy SCSI device preservation is required.

Technical Specifications

Key Features and Advantages

The MVME7616E-001 delivers exceptional signal integrity in electrically noisy environments through its optimized circuit design and shielding. Its dual-protocol support handles both asynchronous and synchronous SCSI communications with equal reliability. The module features built-in diagnostic LEDs for quick visual status monitoring, significantly reducing troubleshooting time. Thermal performance is enhanced through careful component placement and heat dissipation design, allowing continuous operation at maximum rated speeds. The MVME7616E-001 utilizes ruggedized connectors rated for thousands of mating cycles, ensuring long-term reliability in industrial applications. Automatic termination sensing eliminates manual configuration errors, while jumper-selectable ID addressing provides flexible device configuration options.

Application Fields

The MVME7616E-001 excels in industrial automation systems requiring legacy SCSI device integration, particularly in manufacturing execution systems (MES) and distributed control systems (DCS). It’s extensively deployed in semiconductor fabrication equipment for connecting older measurement instruments and wafer handling systems. The oil and gas industry utilizes the MVME7616E-001 for SCADA system upgrades where existing SCSI-based data loggers must be preserved. In power generation facilities, the module serves as a reliable bridge between critical diagnostic equipment and modern control networks. The MVME7616E-001 also supports military/aerospace applications where long-term component availability is essential for system maintenance, including avionics test equipment and ground support systems.

Installation and Maintenance

Installation preparation: Before installing the MVME7616E-001, verify the host VME chassis has proper slot alignment and sufficient cooling capacity. Prepare appropriate SCSI cables with correct termination for your device chain configuration, ensuring cable length does not exceed SCSI specification limits.

Maintenance recommendations: Perform annual inspections of the MVME7616E-001 for dust accumulation, cleaning only with approved anti-static methods. Periodically verify connector integrity and reseat the module every 3-5 years to prevent contact oxidation. Monitor operating temperatures during routine system checks, maintaining ambient conditions within specified limits. Always follow proper ESD precautions when handling the module to prevent static damage to sensitive components.

Product Assurance

Motorola provides comprehensive 12-month warranty coverage for the MVME7616E-001, including protection against manufacturing defects and premature failure under normal operating conditions. Our global technical support network offers expert assistance and rapid replacement services. Each MVME7616E-001 module undergoes rigorous factory testing with full functional verification to ensure reliability. Extended warranty options up to 5 years are available for critical infrastructure applications requiring long-term coverage. Motorola’s commitment to industrial longevity ensures continued availability of the MVME7616E-001 for system lifecycle requirements.
