The Motorola MVME162-011A is an enhanced 32-bit VMEbus embedded controller designed for military-grade industrial automation systems. Building on the legacy of MVME162 series, this model features 64MB ECC-protected DRAM and integrated SCSI-2 interface, making it ideal for high-throughput data acquisition in aerospace test stands and naval combat systems. The MVME162-011A utilizes a Motorola MC68040 processor clocked at 40MHz with 8KB cache, delivering 21 MIPS performance for real-time motion control applications.
As part of Motorola’s rugged computing platform, this controller supports VME64x backplane architecture with 160MB/s sustained data transfer through its dual DMA channels. The extended -40°C to +85°C operating range with conformal-coated PCB enables deployment in arctic exploration vehicles and desert oil drilling rigs. Its front-panel LED matrix provides real-time diagnostics for CPU load, memory errors, and thermal status in nuclear power plant control systems.
Motorola MVME162-011A Enhanced 32-bit VMEbus embedded controller
Key Features and Advantages:
Enhanced data handling: The MVME162-011A’s SCSI-2 interface supports daisy-chaining of up to 7 industrial tape drives or HDDs, ideal for flight data recorder systems. Its 64MB memory configuration enables buffering of 12-hour continuous sensor data in seismic monitoring applications.
Mission-critical reliability: Triple-redundant power inputs with automatic failover ensure 24/7 operation in air traffic control radars. The gold-plated VME P1/P2 connectors withstand 500+ mating cycles in vibration-intensive environments.
Legacy compatibility: Onboard VxWorks BSP supports migration from MVME167 systems. The PMC expansion site accommodates modern interfaces like 10/100 Ethernet (PPMC-100 module) while maintaining legacy I/O support.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | MVME162-011A |
| Manufacturer | Motorola |
| Product Type | VMEbus Embedded Controller |
| Processor | MC68040 @ 40MHz |
| FPU | MC68882 @ 40MHz |
| RAM | 64MB DRAM (ECC) |
| SCSI Interface | Ultra SCSI-2 (20MB/s) |
| VMEbus Support | A32/D32 master with BLT |
| Serial Ports | 2x RS-232/422/485 |
| Watchdog Timer | 0.1-60s programmable |
| Operating Temperature | -40°C to +85°C |
| Power Input | +5V ±5% (12A max) |
| MTBF | 200,000 hours @ 55°C |
| Certifications | MIL-STD-810F, CE, FCC Part 15 |
Application Areas:
The Motorola MVME162-011A excels in:
- Defense Systems: Guided missile telemetry processing
- Energy Sector: Gas turbine control in LNG plants
- Transportation: High-speed train signaling centers
- Heavy Industry: Continuous casting machine controls
In offshore platforms, this controller synchronizes blowout preventer systems with 5ms response time. Automotive test tracks utilize its SCSI interface for parallel data logging from 32 CAN bus nodes.
Related Products:
- MVME162-010A: Base model with 16MB DRAM
- MVME167-033A: PowerPC 750 upgrade path
- PPMC-100: 10/100BASE-T Ethernet PMC
- VME-ADC64: 64-channel analog input board
- MVME162-RTM: Rear transition module
- MVME712M: VME-to-PCI bridge
- Motorola MVME162-213 Embedded control module based on vmebus
Installation and Maintenance:
Installation preparation: Verify VME64x backplane compatibility and allocate 3U vertical space (133.35mm) for MVME162-011A installation. Use torque-controlled extraction tool (P/N VME-TOOL-3) during board insertion to prevent connector damage.
Maintenance recommendations: Perform quarterly SCSI termination resistance checks (90Ω ±5%). Replace CMOS battery (P/N BT-162S) every 3 years using ESD-safe tools. Utilize Motorola’s MVMEmon diagnostics to verify ECC error correction rates biannually.
Product Assurance:
HONG KONG SAUL ELECTRICAL LIMITED provides 12-month comprehensive warranty on MVME162-011A, including free technical consultation for system integration. Our global logistics network guarantees 72-hour emergency replacement for defense sector clients. All units undergo 168-hour thermal cycling tests simulating 10-year operational stress. Legacy firmware updates available through 2030 via authorized service centers.
