The MOOG D136-003-001 is a high-performance ruggedized motion controller (MSC-R) designed for demanding industrial automation applications in harsh environments. As part of MOOG’s MSC series, this freely programmable controller delivers precise motion control for both electric and hydraulic systems. The D136-003-001 combines military-grade durability with advanced control algorithms, making it suitable for extreme operating conditions where standard controllers would fail.
Engineered for reliability, the MOOG D136-003-001 features comprehensive environmental protection and supports multiple communication protocols. Its modular architecture allows for flexible system integration while maintaining the high performance standards expected from MOOG’s industrial motion control solutions.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | D136-003-001 |
| Manufacturer | MOOG |
| Product Type | Ruggedized Motion Controller (MSC-R) |
| Control Axes | Up to 8 axes |
| Control Modes | Position, Velocity, Torque/Force |
| Processor | 32-bit RISC processor @ 500MHz |
| Memory | 512MB DDR3, 4GB Flash |
| Communication Protocols | EtherCAT, CANopen, PROFINET |
| Analog Inputs | 8 channels (16-bit resolution) |
| Analog Outputs | 8 channels (16-bit resolution) |
| Digital I/O | 32 configurable channels |
| Power Supply | 24V DC ±10% (18-32V range) |
| Power Consumption | 60W (max) |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -55°C to +105°C |
| Dimensions | 200mm × 150mm × 60mm |
| Weight | 2.5kg |
| Protection Rating | IP67 (NEMA 6) |
| Vibration Resistance | 10g (5-500Hz) |
| Shock Resistance | 50g (11ms) |
Main Features and Advantages:
The MOOG D136-003-001 delivers exceptional motion control performance with its advanced 32-bit processor architecture, capable of handling complex control algorithms with microsecond-level response times. Its ruggedized design features military-grade components and conformal coating for protection against moisture, dust, and chemical exposure.
Advanced motion control: The controller includes sophisticated algorithms for vibration compensation, adaptive control, and predictive maintenance. The D136-003-001 also features comprehensive diagnostics and built-in self-test capabilities for maximum operational reliability in critical applications.
Application Areas:
- Military & Defense: Vehicle stabilization systems
- Oil & Gas: Offshore drilling equipment
- Mining: Heavy machinery control
- Aerospace: Flight simulator motion systems
- Industrial Automation: Harsh environment robotics
Related Products:
- IC800SSI228RD2-EE S2K Series Stand Alone Motion Controller
- ABB UDC920BE01 3BHE034863R0001 High precision drive interface module
- Emerson DeltaV m Series VE4003S2B1 Traditional I/O modules
- GE H201Ti Dissolved Gas Analysis (DGA) monitor
- Rexroth VT-HNC100-1-23/M-08-P-0 multi-axis servo amplifier
Installation and Maintenance:
Installation preparation: Verify proper environmental sealing and shock/vibration isolation before installing the MOOG D136-003-001. Ensure all connectors are properly seated and locked to maintain IP67 rating.
Maintenance recommendations: Perform annual inspections of all seals and connectors. The D136-003-001 requires minimal maintenance but benefits from periodic firmware updates to ensure optimal performance.
Product Assurance:
MOOG provides a standard 12-month warranty for the D136-003-001. Each unit undergoes extensive environmental testing to ensure reliable operation in extreme conditions.
