The ICS Triplex T8310 is a high-availability expansion processor module designed for critical industrial control systems. Utilizing Honeywell’s patented HIFT (High Integrity Fault Tolerant) TMR architecture, this ruggedized module delivers 99.9999% availability for safety instrumented systems (SIS). The T8310 serves as a processing node in Trusted TMR systems, executing safety logic with <10ms response time for emergency shutdown applications.
Engineered for extreme environments, the T8310 features triple-redundant 32-bit RISC processors with <1μs synchronization skew. Its modular design supports hot-swapping during operation, minimizing downtime in oil/gas and power generation facilities. The module complies with IEC 61508 SIL3 standards for process safety applications.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | T8310 |
| Manufacturer | ICS Triplex (Honeywell) |
| Type | Expansion Processor Module |
| Architecture | HIFT TMR (Triple Modular Redundant) |
| Processors | 3× 32-bit RISC @200MHz |
| Memory | 64MB SRAM + 16MB Flash |
| Scan Time | <10ms (typical) |
| I/O Capacity | 1024 points (max) |
| Communication | TMR Ethernet, RS-485 |
| MTBF | >250,000 hours |
| Operating Temp | -40°C to +70°C |
| Humidity | 5-95% non-condensing |
| Power Supply | 24VDC ±10% |
| Certifications | IEC 61508 SIL3, ATEX Zone 2 |
Key Features and Advantages:
Fault tolerance: The T8310’s HIFT architecture provides continuous operation through concurrent diagnostics and <50ms failover during processor faults. Its patented voter logic detects and isolates faults at hardware level.
Safety compliance: Pre-certified for SIL3 applications with built-in diagnostics covering 99% of dangerous failures. Automatic channel synchronization ensures <1μs timing variance between redundant processors.
Connectivity: Dual-redundant TMR Ethernet ports support 100Mbps communication with HMIs and peer controllers. Integrated web server enables real-time diagnostics without additional software.
Application Areas:
- Oil & Gas: Emergency shutdown systems (ESD)
- Power Generation: Turbine overspeed protection
- Chemical: Burner management systems
- Pharmaceutical: High-integrity batch control
In LNG plants, the T8310 provides SIL3-certified control for cryogenic safety valves.
Related Products:
- T8400: Main processor module
- T8461: Communication gateway
- T8151B: Digital input module
- T8431: Analog output module
- Trusted TMR: Complete system solution
Installation and Maintenance:
Installation preparation: Verify DIN rail spacing meets minimum 50mm clearance for T8310 heat dissipation. Use torque-limiting tools (0.6-0.8Nm) for terminal block connections.
Maintenance recommendations: Perform annual resistance testing (>10MΩ at 500VDC). Clean air vents quarterly using dry nitrogen (<1 bar pressure).
Product Assurance:
Honeywell provides 12-month warranty with lifetime technical support for T8310 modules. Each unit undergoes 2,000-hour burn-in testing including 100 thermal cycles.
