The Honeywell FS-BKM-0001 is a high-reliability battery and key switch module designed for mission-critical industrial control systems, serving as an essential power management component in distributed control architectures. As part of Honeywell’s Field Solutions series, this rugged module provides uninterrupted power supply and secure access control for DCS and PLC systems in demanding industrial environments.
With its intelligent power monitoring capabilities, the FS-BKM-0001 ensures continuous operation during power fluctuations while maintaining strict security protocols through its integrated key switch mechanism. Its modular design allows seamless integration with Honeywell’s Experion PKS and Safety Manager platforms, making it ideal for both process automation and safety instrumented systems.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | FS-BKM-0001 |
| Manufacturer | Honeywell |
| Type | Battery & Key Switch Module |
| Battery Capacity | 7.2Ah @ 24V DC |
| Backup Duration | Up to 72 hours |
| Key Switch Positions | 3 (Off/On/Reset) |
| Operating Voltage | 18-32V DC |
| Power Consumption | 5W typical |
| Operating Temperature | -40°C to +85°C |
| Dimensions | 120mm × 80mm × 40mm |
| Weight | 1.2kg |
| Certifications | SIL 2, ATEX, IEC 61508 |
Key Features and Advantages:
Power reliability: The FS-BKM-0001 incorporates advanced battery management with automatic charge control and health monitoring, ensuring maximum backup power availability when needed most. Its wide operating voltage range accommodates unstable power conditions common in industrial settings.
Security integration: Featuring a rugged mechanical key switch with three-position control, the module provides physical security while enabling system reset functionality without full power cycling. The tamper-proof design prevents unauthorized access attempts while maintaining operational simplicity.
Application Areas:
- Oil & Gas: Backup power for offshore platform control systems
- Chemical Processing: Secure access control for safety shutdown systems
- Power Generation: Battery backup for turbine control panels
- Water Treatment: Power management for remote monitoring stations
Related Products:
- FS-BLIND-COM Dummy communication module
- FS-BKM-0001 Battery and Key switch Module
- FC-PSU-240516 Power Supply Unit 24/5 Vdc, 16 A
- FC-SDI-1648 Safe digital input module (48 Vdc, 16 channels
- FC-SAI-0410 Safe analog input module (4 channels)
- Honeywell FC-QPP-0002 High performance quad-processor Suite
Installation and Maintenance:
Installation preparation: Verify rack space and ventilation before installing the FS-BKM-0001. Ensure proper cable routing and maintain minimum 50mm clearance around the unit for heat dissipation.
Maintenance recommendations: Perform quarterly battery health checks using Honeywell’s Field Diagnostics software. Replace batteries every 3-5 years depending on environmental conditions and usage patterns.
Product Assurance:
Honeywell provides 12-month comprehensive warranty for the FS-BKM-0001, including advance replacement service and 24/7 technical support. Each unit undergoes 500-hour environmental stress testing and full functional validation before shipment.
