The Honeywell CC-TAID01 51306733-175 is a high-performance analog input module designed for precision measurement applications in industrial automation systems. As part of Honeywell’s Experion PKS platform, this OTA (Open Thermocouple Alarm) model provides reliable signal conditioning for various analog sensors including thermocouples, RTDs, and millivolt signals.
Engineered for critical process control applications, the CC-TAID01 51306733-175 features advanced noise rejection technology and 24-bit resolution for exceptional measurement accuracy. Its modular design allows for flexible configuration in distributed control systems while maintaining full compatibility with Honeywell’s C-series I/O architecture. The module serves as a vital interface between field instruments and control processors in demanding industrial environments.
Technical Specifications
Parameter NameParameter ValueModelCC-TAID01 51306733-175ManufacturerHoneywellTypeAnalog Input Module (OTA Model)Input Channels16 single-ended or 8 differentialInput TypesTC (J,K,T,E,R,S,B,N), RTD, mV, VResolution24-bit ADCAccuracy±0.05% of span (typical)Conversion Rate50 samples/second (all channels)Common Mode Rejection>120dB @ 50/60HzInput Impedance>1MΩ for voltage inputsIsolation1500V channel-to-busPower Supply24V DC ±10%Power Consumption5W typicalOperating Temperature-20°C to +70°CHumidity Range5-95% non-condensingDimensions120mm × 80mm × 40mmWeight450gCertificationsUL, CE, ATEX
Key Features and Advantages:
Measurement precision: The CC-TAID01 51306733-175 delivers industry-leading accuracy with its 24-bit sigma-delta ADC and advanced digital filtering technology. Automatic cold junction compensation ensures thermocouple measurements remain accurate across varying ambient temperatures.
Diagnostic capabilities: Built-in open thermocouple detection (OTA) and sensor break monitoring provide early warning of field device failures. The module’s continuous self-diagnostics verify proper operation while maintaining process visibility.
Application Areas:
- Oil & Gas: Wellhead pressure monitoring and temperature surveys
- Chemical Processing: Reactor temperature profiling and batch control
- Power Generation: Turbine bearing temperature monitoring
- Pharmaceutical: Critical process parameter recording for GMP compliance
Related Products:
- CC-TAOX01: Analog output module for complementary signal conditioning
- CC-TDIL01: Digital input module for discrete signal processing
- CC-TDOX01: Digital output module for actuator control
- CC-TAIM01: Current input variant (4-20mA specific)
- CC-TAID02: Next-gen version with enhanced sampling rate
Installation and Maintenance:
Installation preparation: Ensure proper grounding and use twisted-pair shielded cables for all analog signals when installing the CC-TAID01 51306733-175. Maintain minimum clearance from high-voltage cables and verify environmental conditions meet specifications.
Maintenance recommendations: Perform quarterly calibration verification using traceable reference standards. Regularly inspect terminal connections for oxidation and monitor module operating temperature through system diagnostics.
Product Assurance:
Honeywell provides 12-month warranty coverage for the CC-TAID01 51306733-175, including global technical support and firmware update services. Each module undergoes full functional testing and burn-in before shipment to ensure long-term reliability in harsh industrial environments.
