The Honeywell CC-PAON01 represents a premium high-level analog output module designed for precision control applications in industrial automation systems. As part of Honeywell’s C-series I/O family within the Experion PKS platform, this module delivers exceptional signal accuracy for critical process control loops. The CC-PAON01 provides 8 isolated output channels, each capable of generating 4-20mA or 0-10V signals with 16-bit resolution for superior control fidelity.
Engineered for mission-critical applications, the Honeywell CC-PAON01 incorporates advanced diagnostics including output short-circuit detection and load monitoring. Its modular architecture enables seamless integration with existing Honeywell control systems while supporting third-party field devices. The module serves as a reliable interface between distributed control systems and final control elements in continuous process industries.
Technical Specifications
Parameter NameParameter ValueModelCC-PAON01ManufacturerHoneywellTypeHigh-Level Analog Output ModuleOutput Channels8 isolatedSignal Range4-20mA, 0-10V (software selectable)Resolution16-bitAccuracy±0.1% of spanLoad Capacity600Ω max (current output)Update Rate50ms per channelIsolation1500V channel-to-busPower Supply24V DC ±10%Power Consumption6W typicalOperating Temperature-40°C to +70°CHumidity Range5-95% non-condensingDimensions120mm × 80mm × 40mmWeight500gCertificationsATEX, IEC 61508 SIL 2
Main Features and Advantages:
The Honeywell CC-PAON01 delivers industry-leading control accuracy through its high-resolution 16-bit DAC and advanced signal conditioning technology. Each output channel features independent isolation to prevent ground loops and ensure signal integrity in noisy industrial environments. The module’s hot-swappable design enables maintenance without system shutdown when properly configured in redundant systems.
Enhanced diagnostics: Continuous monitoring of output circuit health through built-in short-circuit detection and open-load alarms. The CC-PAON01 provides predictive maintenance data including output drift trends and channel utilization statistics. Its rugged construction withstands severe industrial vibrations and electromagnetic interference.
Application Areas:
- Oil & Gas: Control valve positioning in refinery units
- Chemical Processing: Precise dosing pump control
- Power Generation: Turbine governor valve control
- Pharmaceutical: Critical parameter control for GMP compliance
- Water Treatment: Chemical feed rate adjustment
Related Products:
- CC-PAOH01: HART-enabled analog output variant
- CC-PDON01: Digital output module for discrete control
- CC-PAIN01: Analog input companion module
- CC-PAON02: Next-gen version with enhanced diagnostics
- CC-PCNT01: Pulse counter module for flow applications
Installation and Maintenance:
Installation preparation: Verify proper grounding and use shielded twisted-pair cables for all analog outputs when installing the Honeywell CC-PAON01. Maintain minimum 30cm separation from power cables and confirm environmental conditions meet specifications.
Maintenance recommendations: Perform annual calibration verification using traceable standards. Regularly inspect terminal connections and monitor module diagnostics through system software. The CC-PAON01 supports online replacement without system shutdown when properly configured in redundant architectures.
Product Assurance:
Honeywell provides 12-month warranty coverage for the CC-PAON01, including global technical support and firmware updates. Each module undergoes rigorous testing including 72-hour burn-in and full functional verification.
