Honeywell CC-PAIX02 high-performance analog input module

In stock

The Honeywell CC-PAIX02 is a high-performance analog input module with integrated HART communication protocol support, designed for precision measurement applications in industrial automation systems. As part of Honeywell’s C-series I/O family within the Experion PKS platform, the CC-PAIX02 delivers exceptional signal accuracy for critical process monitoring with 16-bit resolution and advanced diagnostics capabilities. This module provides 8 isolated input channels, each configurable for 4-20mA or 0-10V signals with HART protocol pass-through functionality.

123

The Honeywell CC-PAIX02 is a high-performance analog input module with integrated HART communication protocol support, designed for precision measurement applications in industrial automation systems. As part of Honeywell’s C-series I/O family within the Experion PKS platform, the CC-PAIX02 delivers exceptional signal accuracy for critical process monitoring with 16-bit resolution and advanced diagnostics capabilities. This module provides 8 isolated input channels, each configurable for 4-20mA or 0-10V signals with HART protocol pass-through functionality.

Engineered for mission-critical applications, the Honeywell CC-PAIX02 features channel-to-channel isolation to prevent ground loops and ensure signal integrity in noisy industrial environments. Its modular architecture enables seamless integration with existing Honeywell control systems while supporting communication with HART-enabled field devices. The module serves as a reliable interface between smart field instruments and distributed control systems in continuous process industries.

Technical Specifications

Parameter NameParameter ValueModelCC-PAIX02ManufacturerHoneywellTypeHigh-Level Analog Input with HARTInput Channels8 isolatedSignal Range4-20mA, 0-10V (software selectable)HART SupportYes (pass-through)Resolution16-bitAccuracy±0.1% of spanInput Impedance250Ω (current input)Update Rate50ms per channelIsolation1500V channel-to-busPower Supply24V DC ±10%Power Consumption5W typicalOperating Temperature-40°C to +70°CHumidity Range5-95% non-condensingDimensions120mm × 80mm × 40mmCertificationsATEX, IEC 61508 SIL 2

Main Features and Advantages:

The Honeywell CC-PAIX02 combines high-accuracy signal measurement with HART communication capabilities in a single compact module. Each input channel features independent isolation and advanced signal conditioning to maintain measurement integrity in electrically noisy environments. The module’s hot-swappable design enables maintenance without system shutdown when properly configured in redundant systems.

Enhanced diagnostics include continuous monitoring of signal quality, wire break detection, and HART communication status. The CC-PAIX02 provides predictive maintenance data including signal drift trends and HART device health indicators. Its rugged construction withstands severe industrial vibrations and electromagnetic interference while maintaining measurement accuracy.

Application Areas:

  • Oil & Gas: Wellhead pressure monitoring
  • Chemical Processing: Reactor temperature measurement
  • Power Generation: Turbine vibration monitoring
  • Pharmaceutical: Critical parameter recording for GMP compliance
  • Water Treatment: Flow meter signal conditioning

Related Products:

  1. CC-TAID01 51306733-175 Analog Input module
  2. FC-RUSIO-3224 Remote universal security input/output module
  3. CC-PDOX01: Digital output module
  4. CC-PAIH52: Next-gen analog input with enhanced diagnostics
  5. CC-PCNT01: Pulse counter module

Installation and Maintenance:

Installation preparation: Verify proper grounding and use shielded twisted-pair cables for all analog inputs when installing the Honeywell CC-PAIX02. Maintain minimum 30cm separation from power cables and confirm environmental conditions meet specifications.

Maintenance recommendations: Perform annual calibration verification using traceable standards. Regularly inspect terminal connections and monitor module diagnostics through system software. The CC-PAIX02 supports online replacement without system shutdown when properly configured in redundant architectures.

Product Assurance:

Honeywell provides 12-month warranty coverage for the CC-PAIX02, including global technical support and firmware updates. Each module undergoes rigorous testing including 72-hour burn-in and full functional verification. Lifetime product support ensures long-term availability of spare parts and documentation.
