The Honeywell CC-PAIH01 represents the cutting-edge in analog signal processing technology for industrial automation systems. As part of Honeywell’s C-series I/O modules within the Experion PKS platform, this HART-enabled analog input module provides exceptional measurement accuracy for critical process variables. The CC-PAIH01 supports 16 single-ended or 8 differential input channels, handling signals from 4-20mA transmitters, thermocouples, RTDs, and millivolt sources with 24-bit resolution.
Designed for deployment in harsh industrial environments, the Honeywell CC-PAIH01 integrates advanced diagnostics including wire break detection and out-of-range alerts. Its modular architecture simplifies integration with existing Honeywell control systems while maintaining full compatibility with third-party field devices. The module serves as a reliable interface between field instrumentation and distributed control systems in continuous process applications.
Technical Specifications
Parameter NameParameter ValueModelCC-PAIH01ManufacturerHoneywellTypeAnalog Input Module with HARTInput Channels16 single-ended/8 differentialSignal Range±50mV to ±10V, 0-20mA, TC types J/K/T/E/R/S/B/NHART ProtocolRevision 7 compliantAccuracy±0.05% of spanResolution24-bit ADCUpdate Rate50 samples/second (all channels)Common Mode Rejection>120dB @ 50/60HzIsolation1500V channel-to-channelPower Supply24V DC ±10%Power Consumption4.5W typicalOperating Temperature-40°C to +70°CCertificationsATEX, IECEx, SIL 2
Main Features and Advantages:
The Honeywell CC-PAIH01 delivers unparalleled signal integrity through its patented noise rejection technology and dual-channel isolation design. Its HART communication capability enables simultaneous analog signal processing and digital device configuration without interrupting control loops. The module’s hot-swappable design minimizes downtime during maintenance operations.
Advanced diagnostics: Continuous monitoring of field wiring integrity and sensor health through built-in HART diagnostics. The CC-PAIH01 provides predictive maintenance data including transmitter calibration status and process variable trends. Its rugged construction withstands severe industrial vibrations and electromagnetic interference.
Application Areas:
- Oil & Gas: Custody transfer metering and safety shutdown systems
- Chemical Processing: Reactor temperature monitoring and batch control
- Power Generation: Turbine vibration monitoring and boiler control
- Pharmaceutical: Critical parameter recording for FDA compliance
- Water Treatment: Flow measurement and chemical dosing control
Related Products:
- CC-PAIM01: Current input variant without HART
- CC-PDIM01: Digital input module for discrete signals
- CC-PDOH01: Digital output module with diagnostics
- CC-PAIH02: Next-gen version with enhanced HART capabilities
- CC-PCNT01: Pulse counter module for flow applications
Installation and Maintenance:
Installation preparation: Verify proper grounding and use shielded twisted-pair cables for all analog signals when installing the Honeywell CC-PAIH01. Maintain minimum 30cm separation from power cables and confirm environmental conditions meet specifications.
Maintenance recommendations: Perform annual calibration verification using traceable standards. Regularly inspect terminal connections and monitor module diagnostics through system software. The CC-PAIH01 supports online replacement without system shutdown when properly configured.
Product Assurance:
Honeywell provides 12-month warranty coverage for the CC-PAIH01, including global technical support and firmware updates. Each module undergoes rigorous testing including 72-hour burn-in and full functional verification. Lifetime product support ensures long-term availability of spare parts and documentation.
