The Honeywell 8C-TDILA1 is a high-performance 32-channel terminal board designed for digital input module installation in Honeywell’s Series 8 C300 distributed control system (DCS). This robust interface component provides reliable signal termination and distribution for discrete input signals in industrial automation applications. The 8C-TDILA1 serves as a critical interconnection point between field devices and control modules, ensuring signal integrity and system reliability.
Engineered for seamless integration, the Honeywell 8C-TDILA1 features screw-type terminal blocks with clear channel labeling for simplified wiring. Its modular design allows flexible configuration within C300 I/O racks while maintaining compatibility with various digital input modules. The terminal board provides essential signal conditioning and protection for 24VDC discrete signals in demanding industrial environments, making it an indispensable component in modern DCS architectures.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | 8C-TDILA1 |
| Manufacturer | Honeywell |
| Type | Terminal Board |
| Channels | 32 |
| Compatible Module | Digital Input Modules |
| Terminal Type | Screw clamp |
| Wire Size | 0.2-2.5mm² |
| Isolation Voltage | 1500V channel-to-channel |
| Operating Voltage | 24V DC |
| Current Rating | 5A per channel |
| Operating Temperature | -20°C to 70°C |
| Humidity Range | 5-95% non-condensing |
| Dimensions | 150mm × 100mm × 30mm |
| Weight | 0.5kg |
| Certifications | ATEX, IECEx |
Main Features and Advantages:
The Honeywell 8C-TDILA1 delivers superior signal termination through its high-quality screw terminals with captive pressure plates, ensuring secure connections without wire damage. Each channel features clear numbering and color-coded markings for easy identification during installation and maintenance. The board’s compact design maximizes space utilization while providing excellent accessibility for wiring.
Advanced protection: Built-in isolation barriers prevent ground loops and minimize noise interference. The 8C-TDILA1 features a rugged construction with flame-retardant materials, ensuring long-term reliability in harsh industrial environments. Its modular design supports quick replacement and maintenance without disrupting adjacent components, significantly reducing system downtime.
Application Areas:
- Oil & Gas: Valve position feedback termination
- Power Generation: Circuit breaker status monitoring
- Chemical: Safety interlock system wiring
- Water Treatment: Pump run/stop signal termination
- Manufacturing: Equipment fault signal distribution
Related Products:
- 8C-TDIHA1: High-density terminal board
- 8C-TDOLA1: Digital output terminal board
- 8C-TAILA1: Analog input terminal board
- 8C-TAOHA1: Analog output terminal board
- 8C-TRTDA1: RTD input terminal board
Installation and Maintenance:
Installation preparation: Verify proper grounding and use appropriate wire gauges when connecting to the Honeywell 8C-TDILA1. Ensure environmental conditions meet specifications and maintain proper clearance from high-voltage components.
Maintenance recommendations: Perform annual inspection of all terminal connections and verify proper torque on screw terminals. The 8C-TDILA1 requires minimal routine maintenance when operated within specified environmental conditions.
Product Assurance:
Honeywell provides 12-month warranty coverage for the 8C-TDILA1, including global technical support. Each terminal board undergoes rigorous quality testing to ensure reliable performance in industrial environments. Lifetime product support guarantees long-term availability of documentation and spare parts.
