The GE VMIVME2540 is a high-performance 24-channel intelligent counter/controller module designed for VMEbus-based industrial automation systems. As part of GE’s ruggedized VME product line, this module provides precise frequency measurement up to 10MHz with 32-bit resolution for critical process monitoring applications. The VMIVME2540 features programmable input filters and gate times, making it ideal for turbine monitoring, production counting, and test bench applications.
Engineered for harsh environments, the VMIVME2540 operates across -40°C to +85°C with MIL-STD-810 shock/vibration resistance. Its dual-port memory architecture enables real-time data sharing between VMEbus and local processors.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | VMIVME2540 |
| Manufacturer | GE Intelligent Platforms |
| Type | 24-Channel Counter/Controller |
| Input Channels | 24 (isolated) |
| Frequency Range | 0.001Hz to 10MHz |
| Resolution | 32-bit |
| Accuracy | ±0.01% of reading |
| Input Voltage | 5-30VDC/AC |
| Gate Times | 100ns to 10s (programmable) |
| Interface | VME64x (A32/D32) |
| Operating Temp | -40°C to +85°C |
| Humidity | 5-95% non-condensing |
| Power Supply | +5VDC ±5% |
| Dimensions | 6U × 160mm × 233mm |
Key Features and Advantages:
Measurement precision: The VMIVME2540 achieves 0.01ppm stability with oven-controlled crystal oscillators. Its adaptive filtering eliminates signal noise in electrically noisy environments.
Flexible configuration: Six operating modes (frequency, period, etc.) with software-selectable input coupling (AC/DC). Channel-to-channel isolation prevents ground loops.
Reliability: Conformal coating protects against dust/moisture in paper mills and foundries. Built-in self-test diagnostics reduce MTTR.
Application Areas:
- Power Generation: Turbine blade vibration monitoring
- Steel Production: Rolling mill speed measurement
- Automotive: Engine test stand RPM tracking
- Semiconductor: Wafer handling robot positioning
In hydroelectric plants, the VMIVME2540 monitors generator shaft speeds with <1μs response.
Related Products:
- VMIVME-7750-834 ProcessorBased VME Single Board Computer
- Single-Slot VMIVME-7698 370 Processor-Based VMEbus Single-Board Computer
- VMIC VMIOMAX-9102A Redundant power module
- VME-2532A VMIVME2532A Digital Input/Output Board
- Fanuc/GE VMIVME-4140 32-Channel 12-bit Analog Output Board
- VMIC VMIVME-3122 High-Performance 16-bit Analog-to-Digital Converter Board
Installation and Maintenance:
Installation preparation: Verify VME backplane slot availability before installing VMIVME2540. Use ESD straps when handling modules to prevent static damage.
Maintenance recommendations: Perform annual calibration verification using NIST-traceable sources. Clean card edge connectors biannually with contact cleaner.
Product Assurance:
GE provides 12-month warranty with ISO 17025 accredited calibration services for VMIVME2540. Each unit undergoes 500-hour burn-in testing including thermal cycling.
Note: Requires GE’s Proficy Machine Edition software for advanced configuration. Compatible with RX7i and RX3i PACSystems.
