The GE MIFIIPI55E10HI00 is a high-performance protective relay designed for critical power system protection applications. As part of GE’s Multilin series, this advanced relay provides comprehensive protection for generators, motors, and transformers in industrial and utility power systems.
Featuring state-of-the-art microprocessor technology, the MIFIIPI55E10HI00 offers precise measurement and fast tripping capabilities for various fault conditions. Its modular design allows flexible configuration to meet specific protection requirements, making it an ideal solution for demanding power system applications.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | MIFIIPI55E10HI00 |
| Manufacturer | GE |
| Type | Protective Relay |
| Input Voltage | 24-250V DC/100-240V AC |
| Frequency Range | 45-65Hz |
| Protection Functions | Overcurrent, Differential, Ground Fault |
| Communication Protocols | Modbus, DNP3, IEC 61850 |
| Operating Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Dimensions | 145mm × 178mm × 85mm |
| Weight | 1.2kg |
| Certifications | UL, CE, IEC |
Main Features and Advantages:
The GE MIFIIPI55E10HI00 delivers exceptional protection performance with its advanced algorithms and high-speed processing capabilities. Its modular architecture allows easy customization for specific application requirements.
Advanced diagnostics: The relay features comprehensive self-monitoring and event recording capabilities, enabling quick fault analysis and reduced downtime. The MIFIIPI55E10HI00 maintains reliable operation even in harsh electrical environments.
Application Areas:
- Power Generation: Generator and transformer protection
- Industrial Plants: Motor protection and control
- Utility Networks: Feeder and busbar protection
- Renewable Energy: Solar and wind farm protection
- Oil & Gas: Critical process power system protection
Related Products:
- MIFIIPI55E10HI01: Enhanced version with arc flash protection
- MIFIIPI55E10HI02: Dual-powered version for critical applications
- MIFIIPI55E20HI00: Higher current rating variant
- MIFIIPI55E10LI00: Low-cost version for basic protection
- MIFIIPI55E10HI03: Communication-enhanced version
Installation and Maintenance:
Installation preparation: Verify proper power supply specifications and wiring requirements before installing the GE MIFIIPI55E10HI00. Ensure adequate clearance for ventilation and maintenance access.
Maintenance recommendations: Perform annual functional tests and firmware updates. The MIFIIPI55E10HI00 requires minimal maintenance but benefits from periodic cleaning and inspection of connections.
Product Assurance:
GE offers a 12-month warranty for MIFIIPI55E10HI00. Each unit undergoes rigorous factory testing to ensure reliable performance in critical protection applications.
