The GE IS400TCASH1A is a high-performance turbine control card designed specifically for gas turbine control systems. As a critical component of GE’s Mark VIe turbine control platform, this module provides precise control and monitoring capabilities for industrial gas turbines. The IS400TCASH1A features advanced signal processing and real-time control algorithms, ensuring optimal turbine performance under varying operating conditions.
Engineered for reliability in power generation environments, the GE IS400TCASH1A incorporates ruggedized components capable of withstanding high temperatures and vibration. Its modular design allows for easy integration into existing control cabinets while maintaining the stringent quality standards expected from GE’s power generation products.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | IS400TCASH1A |
| Manufacturer | General Electric |
| Product Type | Turbine Control Card |
| Processor Type | 32-bit industrial grade |
| Clock Speed | 1.2 GHz |
| Memory | 1GB DDR3 |
| Analog Inputs | 16 channels (16-bit resolution) |
| Digital I/O | 32 channels (isolated) |
| Communication Protocols | Ethernet, PROFIBUS DP |
| Operating Voltage | 24V DC ±5% |
| Power Consumption | 25W (max) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | 160mm × 100mm × 30mm |
| Weight | 0.5kg |
Main Features and Advantages:
The GE IS400TCASH1A delivers exceptional control performance with its specialized turbine control algorithms and high-speed processing capabilities. Its advanced signal conditioning circuits ensure accurate measurement of critical turbine parameters, enabling precise control of fuel flow, speed, and temperature.
Safety features: The card incorporates multiple levels of hardware and software protection, including overspeed detection and emergency shutdown capabilities. The IS400TCASH1A also features comprehensive diagnostic functions that provide detailed operational status information for predictive maintenance.
Application Areas:
- Power Generation: Industrial gas turbine control
- Oil & Gas: Compressor station turbine control
- Combined Cycle Plants: Integrated turbine control
- District Heating: Cogeneration systems
- Marine Propulsion: Shipboard turbine systems
Related Products:
- IS400TCASH2A: Enhanced version with additional I/O
- IS400TCASH3A: Extended temperature range model
- IS420PTAS1A: Pressure transmitter interface module
- IS420UCSAH1A: Speed monitoring module
- DS200TCEAG1A: Turbine control expansion card
Installation and Maintenance:
Installation preparation: Verify proper slot compatibility and environmental conditions before installing the GE IS400TCASH1A. Ensure proper grounding and follow ESD precautions during handling.
Maintenance recommendations: Perform regular firmware updates and periodic visual inspections. The IS400TCASH1A benefits from annual preventive maintenance checks to ensure continued reliable operation.
Product Assurance:
GE provides a standard 12-month warranty for the IS400TCASH1A. Each unit undergoes rigorous testing to ensure reliable operation in turbine control applications.
