The ABB DSAO120AK01 3BSE020419R1 is a high-performance 8-channel analog output module designed for industrial automation systems. As part of ABB’s advanced control system components, the DSAO120AK01 3BSE020419R1 provides precise analog signal output for process control applications. The DSAO120AK01 3BSE020419R1 features robust construction and advanced signal conditioning capabilities, making it ideal for critical process control applications. With its modular design and flexible configuration options, the DSAO120AK01 3BSE020419R1 serves as a vital component in distributed control architectures.
Technical Specifications
Product Model | DSAO120AK01 3BSE020419R1
Manufacturer | ABB
Product Type | 8-Channel Analog Output Module
Output Type | 4-20mA/0-20mA/0-10V
Channels | 8 isolated channels
Resolution | 16-bit
Accuracy | ±0.1% of span
Update Rate | 10ms per channel
Operating Voltage | 24VDC ±10%
Power Consumption | 6W typical
Isolation Voltage | 1500V AC
Operating Temperature | -20°C to +70°C
Dimensions | 120mm × 80mm × 40mm
Weight | 0.5kg
Key Features and Advantages
The ABB DSAO120AK01 3BSE020419R1 delivers exceptional performance with its high-resolution analog outputs and channel-to-channel isolation. Each channel provides independent configuration for output type and range, offering unmatched flexibility in field device control. The module features built-in diagnostics for continuous monitoring of output health and wiring integrity. Advanced signal conditioning ensures stable output even in electrically noisy environments. Hot-swappable design allows for maintenance without system shutdown, minimizing production downtime.
Application Fields
The ABB DSAO120AK01 3BSE020419R1 is extensively used in process industries requiring precise analog control. In chemical plants, it controls valve positioning and flow regulation. Power generation facilities utilize this module for turbine control and protection systems. The DSAO120AK01 3BSE020419R1 also serves critical functions in water treatment plants for chemical dosing control and in oil refineries for process variable regulation.
Related Products
- ABB 5SHY3545L0021 integrated gate rectifier thyristor
- CI546 3BSE012545R1 VIP communication interface module
- CS513K01 3BSE004772R1 communication interface module
- ABB PFTL101B 5.0KN 3BSE004191R1 pillow seat load cell
- ABB PD D405 A101 3BHE041626R0101 excitation control unit
Installation and Maintenance
Installation preparation: Before installing the ABB DSAO120AK01 3BSE020419R1, verify proper grounding and power supply specifications. Ensure adequate space for ventilation and cable routing. Prepare appropriate shielded cables for analog signal connections to prevent interference.
Maintenance recommendations: Periodically inspect the DSAO120AK01 3BSE020419R1 for dust accumulation and clean ventilation openings. Verify output calibration annually to maintain signal accuracy. Monitor diagnostic indicators for any abnormal conditions or warning messages.
Product Assurance
ABB provides 24-month warranty coverage for the DSAO120AK01 3BSE020419R1, including protection against manufacturing defects. Our global technical support network offers 24/7 assistance with guaranteed response times. Each DSAO120AK01 3BSE020419R1 undergoes extensive testing to ensure reliability in industrial environments.
