DEIF SCM-1 | SCM-2 synchronization control module
The DEIF SCM-1 is a microprocessor-based synchronization control module designed for precision paralleling of generators in marine and industrial power systems. As part of DEIF’s GPC-3000 power management platform, this IEC 61892-certified module enables seamless load sharing between multiple gensets with ±0.25% voltage matching accuracy. The SCM-1 implements advanced cross-current compensation algorithms to maintain <1° phase angle synchronization during black start operations in offshore platforms.
Featuring dual redundant CANopen interfaces, the DEIF SCM-1 supports J1939 and Modbus RTU protocols for integration with PLCs like Allen-Bradley 1756-L82E or Wärtsilä UNIC C3 systems. Its 24-bit DSP processor calculates 50/60Hz parameters within 10ms cycle time, critical for hospital standby power switchovers. The module’s 4-layer PCB design with conformal coating withstands 97% humidity in tropical marine environments.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | SCM-1 |
| Manufacturer | DEIF |
| Product Type | Generator Synchronization Controller |
| Input Voltage | 24-230VAC/DC (85-264VAC range) |
| Frequency Range | 40-70Hz (±0.01Hz resolution) |
| Phase Matching | <±2° (adjustable deadband) |
| Voltage Matching | ±0.25% of setpoint |
| Communication | 2x CANopen, 1x RS-485 Modbus |
| Relay Outputs | 4 SPDT (5A @ 250VAC) |
| Operating Temp | -25°C to +70°C |
| Housing Protection | IP42 (front)/IP20 (terminals) |
| Certifications | DNV GL, ABS, Lloyds Register |
Key Features and Advantages:
Advanced load anticipation: The SCM-1’s predictive algorithm reduces reverse power risk by analyzing prime mover torque characteristics before closing circuit breakers in data center power plants.
Multi-bus synchronization: Simultaneous monitoring of 3 independent busbars enables complex islanding scenarios in naval vessels. Built-in harmonic distortion analyzer (<2% THD measurement) prevents resonance issues during turbine generator paralleling.
User-programmable curves: Create custom synchroscope characteristics for legacy switchboards using DEIF WinGPS 2.3 software. The front-panel OLED displays vector relationships with 0.1° resolution for quick verification on drilling rig power stations.
Application Areas:
The DEIF SCM-1 is essential in:
- Marine: Synchronizing 690VAC/60Hz gensets on cruise ships
- Oil & Gas: Managing 11kV offshore platform microgrids
- Utilities: Black start coordination for hydroelectric plants
- Construction: Mobile power station load sharing
In LNG carrier electrical systems, the module maintains 400VAC/50Hz synchronization during dynamic positioning operations. Mining operations utilize its vibration-resistant design (5g @ 10-150Hz) for diesel generator paralleling in mobile processing plants. The IEC 60068-2-6 certified shock resistance ensures reliability in wind farm service vessels.
Related Products:
- Power supply module PSM-1
- Control module CM-2
- Current relay module CRM-1
- Binary / analog input module IPM-1
- Analog output module AOM-1
- Motorola MVME162-213 Embedded control module based on vmebus
- Emerson DeltaV m Series VE4003S2B1 Traditional I/O modules
- EasyLine Continuous emission Monitoring system EL3020
Article Recommendation ：ABB AC800PEC Series controllers: The intelligent core of industrial automation Click to read
Installation and Maintenance:
Installation preparation: Verify CT polarity using DEIF-supplied test harness before connecting SCM-1 to generator current transformers. Maintain 100mm clearance from high-voltage cables in switchroom installations.
Maintenance recommendations: Perform annual calibration using DEIF Calibration Kit CK-3000. Clean optical isolation slots every 6 months in desert environments. Replace backup lithium battery (CR2450) every 5 years to preserve event logs during power outages.
Product Assurance:
HONG KONG SAUL ELECTRICAL LIMITED provides 12-month extended warranty for SCM-1 modules, including free firmware upgrades for IEC 61892-2018 compliance. Each unit undergoes 72-hour burn-in testing with simulated 400VAC/65Hz stress cycles. Our global service network guarantees 24-hour technical support for critical power system installations. Complete type approval certificates and marine compliance documents accompany every shipment.
