The ABB CS513K01 3BSE004772R1 is a high-performance communication interface module designed for industrial automation systems. As part of ABB’s MasterBus 300 series, the CS513K01 3BSE004772R1 provides reliable data exchange between field devices and control systems. The CS513K01 3BSE004772R1 features robust construction and advanced protocol handling capabilities, making it ideal for mission-critical process control applications. With its modular design and flexible configuration options, the CS513K01 3BSE004772R1 serves as a vital communication hub in distributed control architectures.
Technical Specifications
Product Model | CS513K01 3BSE004772R1
Manufacturer | ABB
Product Type | MasterBus 300 Communication Interface Module
Protocol Support | MasterBus 300, Modbus RTU
Data Transfer Rate | 1.5Mbps maximum
Operating Voltage | 24VDC ±10%
Power Consumption | 6W typical
Isolation Voltage | 1500V AC
Operating Temperature | -25°C to +60°C
Humidity Range | 5% to 95% non-condensing
Dimensions | 110mm × 80mm × 35mm
Weight | 0.4kg
Protection Class | IP20
Key Features and Advantages
The ABB CS513K01 3BSE004772R1 delivers exceptional communication performance with its dual-channel architecture and advanced error detection capabilities. Its galvanic isolation ensures reliable operation in electrically noisy environments, while the built-in diagnostic LEDs provide real-time status monitoring. The CS513K01 3BSE004772R1 supports automatic baud rate detection and protocol conversion, simplifying system integration. Its compact form factor allows for space-efficient installation in control cabinets, and the module’s firmware is field-upgradable for future compatibility.
Application Fields
The ABB CS513K01 3BSE004772R1 is extensively used in industrial automation networks requiring reliable fieldbus communication. In power generation plants, it facilitates communication between turbines and DCS systems. Oil refineries utilize this module for process control and safety system integration. The CS513K01 3BSE004772R1 also serves critical functions in water treatment facilities and chemical processing plants where robust communication is essential.
