The ABB PPD513AOC-100440 3BHE039724R0C3D is a high-performance excitation hybrid input/output device designed for power generation applications. As part of ABB’s renowned excitation control system portfolio, this device provides reliable signal processing and control capabilities for generator excitation systems. The PPD513AOC-100440 3BHE039724R0C3D serves as a critical interface between excitation controllers and field equipment, offering both analog and digital signal processing capabilities.
With its rugged design and advanced protection features, the ABB PPD513AOC-100440 3BHE039724R0C3D ensures stable operation in demanding power plant environments. Its modular architecture allows for easy integration with existing excitation systems while maintaining the high reliability standards expected from ABB products.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | PPD513AOC-100440 3BHE039724R0C3D |
| Manufacturer | ABB |
| Product Type | Excitation Hybrid I/O Device |
| Input Voltage Range | 24V DC ±10% |
| Power Consumption | 25W max |
| Analog Inputs | 16 channels (4-20mA/0-10V) |
| Digital Inputs | 32 channels (24V DC) |
| Analog Outputs | 8 channels (4-20mA) |
| Digital Outputs | 16 channels (relay contacts) |
| Communication Interface | PROFIBUS DP |
| Operating Temperature | -20°C to +60°C |
| Protection Rating | IP20 |
| Dimensions | 200mm × 150mm × 80mm |
| Weight | 2.5kg |
Main Features and Advantages:
The ABB PPD513AOC-100440 3BHE039724R0C3D excels with its hybrid signal processing capability, supporting both analog and digital signals in a single compact unit. Its high-density I/O configuration reduces cabinet space requirements while maintaining excellent signal integrity.
Advanced protection: The device features comprehensive electrical isolation between channels and built-in surge protection for reliable operation in electrically noisy environments. The PPD513AOC-100440 3BHE039724R0C3D also includes self-diagnostic functions for preventive maintenance.
Application Areas:
- Power Generation: Generator excitation control
- Hydroelectric Plants: Turbine governor systems
- Industrial Power Systems: Synchronous motor control
- Renewable Energy: Excitation for synchronous condensers
Related Products:
- ABB PPD 517 A3011 3BHE041576R3011 excitation controller
- Control system PPD113B01-23-111000 AC800PEC 3BHE023784R2330
- PPD539A102 3BHE039770R0102 AC 800PEC Controller equipment
- PCD530A102 3BHE041343R0102 High performance controller for excitation system
- GFD233A103 3BH022294R0103 high-performance rectifier controller
Installation and Maintenance:
Installation preparation: Verify proper mounting location and power supply before installing the ABB PPD513AOC-100440 3BHE039724R0C3D. Ensure adequate clearance for ventilation and proper cable management for optimal signal integrity.
Maintenance recommendations: Perform annual calibration checks and periodic visual inspections. The PPD513AOC-100440 3BHE039724R0C3D requires minimal maintenance but benefits from regular firmware updates for optimal performance.
Product Assurance:
ABB provides a standard 12-month warranty for the PPD513AOC-100440 3BHE039724R0C3D. Each unit undergoes extensive testing to ensure reliable operation in critical power generation applications.
