The ABB 086370-001 is a high-performance information processing and communication module designed for industrial automation systems. As part of ABB’s renowned control system components, this module serves as a critical interface between field devices and control systems in distributed control architectures. The 086370-001 module provides reliable data exchange capabilities with advanced protocol support, making it essential for modern industrial communication networks.
With robust processing capabilities, the ABB 086370-001 enables seamless integration between different levels of industrial control systems, from field devices to enterprise networks. Its modular design ensures easy installation and maintenance while delivering the high reliability expected from ABB products.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | 086370-001 |
| Manufacturer | ABB |
| Product Type | Information Processing Communication Module |
| Power Supply | 24V DC ±10% |
| Power Consumption | 5W max |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Communication Protocols | PROFIBUS DP, Modbus RTU, Ethernet/IP |
| Data Transfer Rate | Up to 12Mbps |
| Isolation Voltage | 1500V AC |
| Dimensions | 120mm × 80mm × 40mm |
| Weight | 0.5kg |
| Certifications | CE, UL, ATEX |
Main Features and Advantages:
The ABB 086370-001 stands out with its multi-protocol support, allowing seamless integration with various industrial networks. Its rugged design ensures reliable operation in harsh industrial environments, with excellent resistance to vibration and electromagnetic interference.
Advanced diagnostics: The module features comprehensive self-diagnostic capabilities with LED status indicators for quick troubleshooting. The 086370-001 also supports hot-swapping in compatible systems, minimizing downtime during maintenance or replacement.
Application Areas:
- Power Generation: Distributed control system communications3
- Oil & Gas: Field device network integration
- Manufacturing: PLC-to-PLC communication links
- Water Treatment: SCADA system data acquisition
- Mining: Remote I/O communication networks
Related Products:
- 086348-002: Enhanced version with additional protocol support
- 086348-003: High-speed Ethernet communication module
- 086349-001: Power supply unit for communication modules
- 086350-001: Redundant communication module
- 086351-001: Fiber optic communication interface
Installation and Maintenance:
Installation preparation: Verify proper power supply and grounding before installing the ABB 086370-001. Ensure adequate clearance for ventilation and proper cable management for signal integrity.
Maintenance recommendations: Perform annual firmware updates and periodic visual inspections. The 086370-001 requires minimal maintenance but benefits from regular cleaning to prevent dust accumulation.
Product Assurance:
ABB provides a standard 12-month warranty for the 086370-001. Each module undergoes rigorous testing to ensure compliance with industrial standards and reliable performance in critical applications.
