The ABB 500CIM05 1MRB150077R1B is a high-performance Ethernet communication module designed for industrial automation networks. As part of ABB’s 500 series communication modules, this device provides reliable data transmission between control systems and field devices in demanding industrial environments. The 500CIM05 1MRB150077R1B serves as a critical network interface component, enabling seamless integration of PLCs, DCS systems and other automation equipment.
With its rugged industrial design, the ABB 500CIM05 1MRB150077R1B ensures stable operation in harsh conditions including extreme temperatures and electrical noise. Its modular architecture allows for easy installation and maintenance while meeting the high reliability standards expected from ABB products.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | 500CIM05 1MRB150077R1B |
| Manufacturer | ABB |
| Product Type | Ethernet Communication Module |
| Network Standard | IEEE 802.3 10/100BASE-TX |
| Protocol Support | Modbus TCP, PROFINET, EtherNet/IP |
| Data Rate | 10/100 Mbps (auto-negotiation) |
| Connection Ports | 2× RJ45 (auto MDI/MDI-X) |
| Isolation Voltage | 1500V AC (port-to-port) |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Power Supply | 24V DC ±10% |
| Power Consumption | 3W max |
| Dimensions | 120mm × 90mm × 35mm |
| Weight | 0.4kg |
Main Features and Advantages:
The ABB 500CIM05 1MRB150077R1B delivers exceptional network performance with its dual-port architecture supporting simultaneous communication paths. Its industrial-grade components ensure reliable operation in electrically noisy environments common in factory automation.
Advanced diagnostics: The module features comprehensive network monitoring capabilities including link status indicators, traffic monitoring and error detection. The 500CIM05 1MRB150077R1B also includes built-in surge protection and electrical isolation for enhanced reliability.
Application Areas:
- Manufacturing: Production line control networks
- Power Generation: Plant monitoring systems
- Oil & Gas: Pipeline SCADA communications
- Water Treatment: Remote monitoring networks
- Transportation: Signal control systems
Installation and Maintenance:
Installation preparation: Verify proper mounting location and network infrastructure before installing the ABB 500CIM05 1MRB150077R1B. Ensure adequate cable management and proper grounding for optimal signal integrity.
Maintenance recommendations: Perform periodic visual inspections and firmware updates. The 500CIM05 1MRB150077R1B requires minimal maintenance but benefits from regular network performance monitoring.
Product Assurance:
ABB provides a standard 36-month warranty for the 500CIM05 1MRB150077R1B, including technical support and replacement services. Each unit undergoes extensive testing to ensure reliable operation in critical industrial applications.
